Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/T5 Series/CP860/CP920 IP Phones
552
Parameters
Permitted Values
Default
X=1-10, 14 (for SIP-T23P/T23G/T21(P) E2)
For ext keys:
For SIP-T54S/T52S:
X ranges from 1 to 3, Y ranges from 1 to 60.
For SIP-T48G/T48S/T46G/T46S:
X ranges from 1 to 6, Y ranges from 1 to 40.
For SIP-T29G/T27P/T27G:
X ranges from 1 to 6, Y ranges from 1 to 20, 22 to 40 (Ext key 21 cannot be configured).
Example:
linekey.2.pickup_value = *20*
Note: This parameter only applies to intercom and BLF features. It is not applicable to SIP-
T19(P) E2 IP phones.
Web User Interface:
Dsskey->Line Key/Programable Key->Extension
Phone User Interface:
Menu->Features->DSS Keys->Line Key X->Extension
linekey.X.label/ programablekey.X.label/
expansion_module.X.key.Y.label
String within 99
characters
Blank
Description:
(Optional.) Configures the label displayed on the LCD screen for each DSS key.
For line keys:
X ranges from 1 to 29 (for SIP-T48G/S)
X ranges from 1 to 27 (for SIP-T54S/T46G/T46S/T29G)
X ranges from 1 to 15 (for SIP-T42G/T42S/T41P/T41S)
X ranges from 1 to 21 (for SIP-T52S/T27P/T27G)
X ranges from 1 to 3 (for SIP-T40P/T40G/T23P/T23G)
X ranges from 1 to 2 (for SIP-T21(P) E2)
For programable keys:
X ranges from 1 to 4.
For ext keys:
For SIP-T54S/T52S:
X ranges from 1 to 3, Y ranges from 1 to 60.
For SIP-T48G/T48S/T46G/T46S:
X ranges from 1 to 6, Y ranges from 1 to 40.
For SIP-T29G/T27P/T27G:
