response indicates that User B accepts
the transfer.
BYE—User A to Proxy Server
User A terminates the call session by
sending a SIP BYE request to the proxy
server. The BYE request indicates that
User A wants to release the call.
BYE—Proxy Server to User B
The proxy server forwards the BYE
request to User B.
200OK—User B to Proxy
Server
User B sends a SIP 200 OK response to
the proxy server. The 200 OK response
notifies User A that User B has received
the BYE request.
200OK—Proxy Server to User
A
The proxy server forwards the SIP 200
OK response to User A.
The following figure illustrates successful call forwarding between Yealink SIP IP phones
in which User B has enabled always call forward. The incoming call is immediately
forwarded to User C when User A calls User B. In this call flow scenario, the end users
are User A, User B, and User C. They are all using Yealink SIP IP phones, which are
connected via an IP network.
The call flow scenario is as follows:
1. User B enables always call forward, and the destination number is User C.
2. User A calls User B.
3. User B forwards the incoming call to User C.
