Yealink SIP-T41S Administrator's Guide

Phone Provisioning
100
[T42S]features.dnd.enable = 0
Custom configuration file:
Linekey.cfg
linekey.2.type=13
linekey.2.line=1
linekey.2.value = 4603
linekey.2.label=Bill
MAC-Oriented configuration files:
001565b09d886.cfg
account.1.enable = 1
account.1.label = Bill
account.1.display_name = 1023
account.1.auth_name = 1023
account.1.user_name = 1023
account.1.password = 1023
account.1.sip_server.1.address = 10.2.1.199
account.1.sip_server.1.port = 5060
3.
Place the configuration files to the home directory of the provisioning server. For example, D:\TFTP Provision.
4.
Specify the configuration files paths in the boot file as desired. For example,
y000000000000.boot
include:config<tftp:/10.2.5.193/CustomSettings.cfg>
[T46S,T48S]include:config “tftp:/10.2.5.193/Linekey.cfg”
001565b09d886.boot
include:config<tftp:/10.2.5.193/Linekey.cfg>
include:config<tftp:/10.2.5.193/001565b09d886.cfg>
5.
Place the boot files to the home directory of the provisioning server. For example, D:\TFTP Provision.
6.
Reboot the phones to trigger auto provisioning.
For the phone with MAC 001565b09d886, it will download the 001565b09d886.boot file, and then download
Linekey.cfg and 001565b09d886.cfg files referenced in the 001565b09d886.boot file in sequence from the pro-
visioning server.
For the phones except for MAC-specific phone, they will request to download the y000000000000.boot file, and
then request to download the referenced files. The phone-specific configuration file Linekey.cfg only applies to
T46S and T48S phones. The only difference is that T46S and T48S phones will download both the two files since
the exclude mode is disabled by default. The other phones will only download the CustomSettings.cfg file.
For the parameter settings in the CustomSettings.cfg file, the phone-specific parameters will only take effect on the
specific phone models.
The following shows the provisioning flowchart for different phone models with phone-specific settings.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
