Yealink SIP-T41S Administrator's Guide

Phone Customization
243
l The value of attributes in a line element is the default value of the corresponding attribute in the key element. For
example, if you have not configured the width attribute in the key element, the key will automatically use the
value of width attribute configured in line element as the width.
l The size of the onscreen keyboard is 800 pixels wide by 256 pixels high. If the area of the keyboard you con-
figured is larger than the size of the keyboard, the part of the area beyond the keyboard will not be shown.
Customizing a Layout File
1.
Open the template file.
2.
Edit the corresponding string in the file.
3.
Save the change and place this file to the provisioning server.
Input Method Configuration
The following table lists the parameters you can use to configure the input method.
Parameter
gui_input_method.url <y0000000000xx>.cfg
Description
It configures the access URL of the custom keypad input method file for the phone user interface.
Example:
gui_input_method.url = http://192.168.10.25/custom_ime.txt
During the auto provisioning process, the phone connects to the provisioning server “192.168.1.25”,
and downloads the custom keypad input method file “custom_ime.txt”.
gui_input_method.url = http://192.168.10.25/Russian_ime.txt
During auto provisioning, the phone connects to the provisioning server “192.168.1.25”, and down-
loads the custom keypad input method file “Russian_ime.txt“ for the Russian language.
Note: If you want to upload a custom keypad input method file for the desired language, you can
name the file “language name_ime.txt”. The valid language names are: English, Chinese_S,
Chinese_T, French_CA, French, German, Italian, Polish, Portuguese, Portuguese_LA, Spanish, Span-

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
