Yealink SIP-T41S Administrator's Guide

Advanced Features
432
Default
60
Web UI
Features > ACD > ACD > ACD Auto Available Timer (0~120s)
[1]
X is the account ID. For T57W/T54W/T48U/T48S/T48G/T46U/T46S/T46G/T29G, X=1-16; for
T53W/T53/T43U/T42G/T42U/T42S, X=1-12; for T41P/T41S/T27G, X=1-6; for T40P/T40G/T23P/T23G, X=1-3; for T21
(P) E2, X=1-2; for T19(P) E2/CP920, X=1.
Example: Setting ACD
The following example shows the configuration for ACD.
Example
######Set an ACD for account 1#######
account.1.acd.enable = 1
account.1.acd.available = 1
account.1.subscribe_acd_expires = 3000
acd.enable = 1
acd.auto_available_timer = 60
features.homescreen_softkey.acd.enable = 1
######Set an ACD key#############
linekey.1.type=42
linekey.1.label=ACD
After provisioning, you can press the Login soft key or ACD key to log into the ACD system. After logging into the
ACD system, Available (Avail)/Unavailable (Unavail) soft key appears on the phone screen. You can press Avail-
able (Avail)/Unavailable (Unavail) soft key to change ACD state. The ACD key on the IP phone indicates the ACD
state.
Busy Lamp Field
The Busy Lamp Field (BLF) feature enables the IP phone to monitor specific remote lines for state changes on the
phone. It is not available on the T19(P) E2/CP920 IP phone.
Yealink phones support two methods of BLF configuration:
l Configure a line key as BLF key to monitor a specific remote line
l Configure BLF List to monitor a list of specific remote lines
The BLF feature enables the following functions to the users:
l Monitor the status of line on their phone
l Display caller ID information
l Answer incoming calls to the monitored line (called directed call pickup)
l Park and retrieve calls to the monitored line
l Initiate an outgoing intercom call to the monitored line
l Barging In an Active Call by BLF List Key
l Park the active call to the monitored users who are in the BLF list
Topics
BLF Key Configuration
BLF List Configuration
State Indicator of Remote Line
BLF/BLF List Subscription

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
