Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
477
Contact: <sip:3586@10.2.40.27:5063 >
Max-Forwards: 70
User-Agent: Yealink SIP-T46G
Event: ACTION-URI
Content-Type: message/sipfrag
Content-Length: 6
Message Body
key=OK
Variable Values List
Yealink phones also support a combination of the variable values in the URI, but the order of the variable value is
determined by the operation of the phone. The valid URI format is: http(s)://<phoneIPAddress>/servlet?key=variable
value[;variable value]. Variable values are separated by a semicolon from each other. This method is not applicable
to T57W/T48U/T48S/T48G phones.
The following shows an example for deleting all entries from the call history list when the phone is idle:
For CP920 phones:
http://10.3.20.10/servlet?key=F1;OK;F3;DOWN;DOWN;DOWN;OK;OK.
For other phones:
http://10.3.20.10/servlet?key=F1;F3;DOWN;DOWN;DOWN;OK;OK.
Note: The variable value is not applicable to all events. For example, the variable value “MUTE” is only applicable when the
IP phone is during a call.
When authentication is required, you can use the following URI format: http(s)://user-
name:password@<phoneIPAddress>/servlet?key=variable value. If you are using a browser, we recommend that
you use Firefox.
The following table lists predefined variable values:
Variable Value Phone Action
OK Press the OK/√key. (not applicable to T57W phones)
ENTER
Press the Enter soft key. (not applicable to T57W/T48U/T48S/T48G
phones)
SPEAKER Press the Speakerphone key. (not applicable to CP920 phones)
F_TRANSFER Transfer a call to another party.
VOLUME_UP Increase the volume.
VOLUME_DOWN Decrease volume.
MUTE Mute a call.
F_HOLD/HOLD Place an active call on hold.
F_CONFERENCE
Press the Conf/Conference soft key.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
