FXS Gateway TA400/800 User Manual
Note:
TA FXS Gateway is not the VLAN server, a 3-layer switch is still needed, please
configure the VLAN information there first, then input the details in TA FXS Gateway,
so that the packages via TA FXS Gateway will be added the VLAN label before
sending to that switch.
Figure 3-5 VLAN Settings
Table 3-3 Description of VLAN Settings
Items
Description
NO.1
Click the NO.1 you can edit the first VLAN over LAN
VLAN Number
The VLAN Number is a unique value you assign to each
VLAN on a single device
VLAN IP Address
Set the IP Address for TA FXS Gateway VLAN over LAN.
VLAN Subnet Mask
Set the Subnet Mask for TA FXS Gateway VLAN over LAN.
Default Gateway
Set the Default Gateway for TA FXS Gateway VLAN over LAN
NO.2
Click the NO.2 you can edit the first VLAN over LAN.
VLAN Number
The VLAN Number is a unique value you assign to each
VLAN on a single device.
VLAN IP Address
Set the IP Address for TA FXS Gateway VLAN over LAN.
VLAN Subnet Mask
Set the Subnet Mask for TA FXS Gateway VLAN over LAN.
Default Gateway
Set the Default Gateway for TA FXS Gateway VLAN over
LAN.
3.1.4 VPN Settings
A virtual private network (VPN) is a method of computer networking typically using the
public internet that allows users to privately share information between remote
locations, or between a remote location and a business' home network. A VPN can
provide secure information transport by authenticating users, and encrypting data to
prevent unauthorized persons from reading the information transmitted. The VPN can
be used to send any kind of network traffic securely. TA FXS Gateway supports
OpenVPN.
12/59
