FXS Gateway TA400/800 User Manual
Two Methods are supported for TA FXS Gateway provision: PnP and DHCP.
If DHCP method is selected, you should enable DHCP Server on MyPBX (System→
Network Preferences→DHCP Server).
Figure 3-27 TA FXS Gateway Gateway Auto Provision
3.3.5 Firmware Update
Firmware upgrading is possible through the Administrator Web interface using a
TFTP Server or an HTTP URL. Enter your TFTP Server IP address and firmware file
location, then click "Start" to update the firmware
Notes:
1. If “Reset configuration to Factory Defaults” is enabled, the system will restore to
factory default settings.
2. When updating the firmware, please don’t turn off the power. Or the system will get
damaged.
Figure 3-28 Firmware Update
3.3.6 Backup and Restore
We can back up the configurations before resetting TA FXS Gateway to factory
defaults, and then restore it on this package.
Figure 3-29 Backup and Restore
27/59
