FXS Gateway TA400/800 User Manual
Figure 4-28 Tone Zone Settings
Users may also configure the tone zone according to the national standard by
selecting "User custom for Tone Zone". Please refer to the document below and
configure the tone zone settings on TA FXS Gateway:
http://www.itu.int/ITU-T/inr/forms/files/tones-0203.pdf
Figure 4-29 Customize Tones
Table 4-14 Description of Tone Zone Settings
Country
Choose the country to get pre-programmed tone zone settings or
choose "User custom for Tone Zone" to configure the settings
manually.
Ring Cadence
Configuration option for all FXS ports ring cadence for all
incoming calls.
Prompt tone of off-hook dial tone.
The tone sent to caller when ringing is on.
Used for busy line prompt.
Used for notification in call waiting.
Congestion Tone
Used to indicate that an invalid code has been dialed, or that all
circuits (trunks) are busy and/or the call is unroutable.
Used for the second stage dial tone.
53/59
