TA410/810 User Manual
50/63
Table 10-4 Description of Auto Defense
The port you want to auto defense, for example, 8022.
Select the protocol. You can select UDP or TCP.
The maximum packets or connections can be handled per unit
time. For example, if you configure it as below:
Port: 8022
Protocol: TCP
Rate: 10/min
Then, it means maximum 10 TCP connections can be handled in
1 minute. The 11
th
connection will be dropped.
IP Blacklist
You can set some packets accept speed rules here. When an IP address, which
hasn’t been accepted in common rules, sends packets faster than the allowed speed,
it will be set as a black IP address and be blocked automatically.
Figure 10-10 IP Blacklist Settings Page
1) Blacklist rules
We can add the rules for IP blacklist rate as demanded.
Figure 10-11 Add Blacklist Rule
