36 IM 04P02B01-02E
Selecting the Input Type
5.
Press the key to select 1-5V and then press the key (see “Explanation”
on page 39).
Mode=1-5V
Scales and records the
Setting Span Left
6.
Set Span left to 1.000 and press the key.
Press the key to select the desired digit.
Press the
key to select the value.
Span left= 1.000
0.800/ 1.200V
Displays the range of Span left.
Setting Span Right
7.
Likewise, set Span right to 5.000 and press the key.
Span right= 5.000
4.800/ 5.200V
Displays the range of Span right.
Setting the Decimal Position and Scaling Left
8.
Display Scale left.
Scale left= 0.00
-200.00/ 300.00 Decima
Displays the scaling range.
9.
Press the key to select the desired digit.
Scale left= 0.00
-200.00/ 300.00 Decima
10.
Press the key to select space and then press the key (Scale left is set
to 0.0).
Scale left= 0.0
-200.00/ 300.00 Decima
Setting Scaling Right
11.
Likewise, set Scale right to 500.0 and press the key.
Scale right= 500.0
-2000.0/ 3000.0
Displays the scaling range.
The Setting complete screen is displayed. When this screen is displayed, the
settings entered up to then are applied.
Finishing the Settings
12.
When Setting complete screen is displayed, press the ESC key.
The Set=Range screen is displayed.
03-03 Channel
Setting complete
Set=Range
Input range and record
Setting the Unit
13.
Press the key to select Unit and then press the key.
Set=Unit
Engineering unit for l
Displays the description of setting item.
14.
Press the key to set the first channel to 03 and then press the key.
First channel
Last channel
CH=03-03
First channel 01-06
Displays the selectable range of channels.
15.
Likewise, set the last channel to 03 and then press the key.
Setting the Input Range and Alarm on Measurement Channels
* When the key or key is pressed while holding down the SHIFT key, the operation is
reversed as when the respective key is pressed by itself.
To Next Page
