55IM 04P02B01-02E
Setup Item Pen/Dot Selectable Range or Selections Default Value
*Batch > Detail > End > Action > POC output
Pen Model On/Off Off
*Batch > Detail > End > Action > POC speed
Pen Model C.Speed/450 mm h C.Speed
*Batch > Detail > Start2 ... Same as Start
*Batch > Detail > End2 ... Same as End
*Batch > MSG format > Message No.
- 1/2/3/4/5 1
*Batch > MSG format > Message No. > (MSG format)
- 69 characters or less H:M L16
Setup Items in Basic Setting Mode and Their Default Values (Firmware version: 1.31)
Setup Item Pen/Dot Selectable Range or Selections Default Value
Alarm > Diagnosis - On/Off Off
Alarm > Reflash - On/Off Off
Alarm > AND - None/I01/I01-I02/I01-I03/I01-I04/I01-I05/ None
I01-I06/I01-I11/I01-I12/I01-I13/I01-I14/
I01-I15/I01-I16/I01-I21/I01-I22/I01-I23/
I01-I24/I01-I25/I01-I26/I01-I31/I01-I32/
I01-I33/I01-I34/I01-I35/I01-I36
Alarm > Act - Energize/De_energize Energize
Alarm > Behavior - Nonhold/Hold Nonhold
Alarm > Indicator - Nonhold/Hold Nonhold
Alarm > Increase - 01 to 15 01
Alarm > Decrease - 01 to 15 01
Alarm > Hysteresis - Off/0.1% to 1.0% 0.5%
Alarm > Math hysteresis - Off/0.1% to 1.0% Off
A/D > Integrate Dot Model Auto/50Hz/60Hz/100ms Auto
Pen Model Auto/50Hz/60Hz Auto
Burnout > CH - 01 to 24 01
Burnout > Burnout - Off/Up/Down Off
RJC > CH - 01 to 24 01
RJC > RJC - Internal/External Internal
RJC > RJC > Volt - –20000 to 20000 µV0 µV
Color > Channel Dot Model 01 to 24 01, 07, 13, 19: Purple
Color > Color Dot Model Purple/Red/Green/Blue/Brown/Black 02, 08, 14, 20: Red
03, 09, 15, 21: Green
04, 10, 16, 22: Blue
05, 11, 17, 23: Brown
06, 12, 18, 24: Black
POC > POC Pen Model On/Off Off
Print > CH/Tag - CH/Tag CH
Print > Channel Dot Model On/Off On
Print > Alarm - On1/On2/Off On1
Print > Record On - On/Off Off
Print > Chart speed - On/Off On
Print > Scale - On/Off On
Print > Pen color Pen Model On/Off On
Print1 > Periodic - Auto/Manual Auto
Print1 > Ref. Time - Hour 0 to 23 (1 hour steps) 00:00
Print1 > Interval - 10min/15min/20min/30min/1h/2h/3h/4h 1h
/6h/8h/12h/24h
Print1 > Mode - Inst/Report/Off Inst
Print2 > CH - 01 to 24 01
Print2 > Mode - AVE/MIX/SUM/MIN/MAX/INST AVE
Print2 > SUM scale - Off, /s, /min, /h, /day Off
Bar graph > CH - 01 to 24 01
Bar graph > Graph - Normal/Center Normal
Keylock > Keylock - Not/Use Not
Keylock > Password - Numbers and spaces within 4 digits Blank
Keylock > RCD - Free/Lock Free
Keylock > Feed - Free/Lock Free
Keylock > Menu - Free/Lock Free
Keylock > Disp Menu - Free/Lock Free
Keylock > Alarm ACK - Free/Lock Free
Keylock > Math - Free/Lock Free
Keylock > Print out - Free/Lock Free
Keylock > Message - Free/Lock Free
Keylock > Buffer clear - Free/Lock Free
Setup Items and Default Values
