5. EXPLANATION OF BASIC ITEMS
DISPLAY_SELECT1, 2, 3:
Table 5.3.1 DISPLAY SELECT
DISPLAY_SELECT 1 DISPL AY_SELE CT 2 DISPL AY_SELE CT 3
The display content for the display
unit's first line.
The display content for the display unit's
second line.
The display content for the display
unit's third line.
1:Flow Rate(%) 1:Off 1:Off
2:Flow Rate 2:Flow Rate(%) 2:Flow Rate(%)
3:Integrator1 Out 3:Flow Rate 3:Flow Rate
4:Integrator2 Out 4:Flow Rate(Bar) 4:Flow Rate(Bar)
5:Arithmetic Out 5:Integrator1 Out 5:Integrator1 Out
6:Integrator2 Out 6:Integrator2 Out
The factory default setting is 2. 7:Arithmetic Out 7:Arithmetic Out
8:PD Tag 8:PD Tag
9:Adhesion Check 9:Adhesion Check
10:Communication 10:Communication
The factory default set ting is 1. The factory default setting is
T0501.eps
1.
DISPLAY_CYCLE:
Sets the cycle of LCD display. The factory default
setting of the display cycle is 2: 400ms. The valid
range can be selected from below;
1: 200ms
2: 400ms
3: 1s
4: 2s
5: 4s
6: 8s
If the low temperature environment makes it difficult
to view the display, it is recommended that you set a
longer display cycle.
PRIMARY_VALUE_TYPE:
Indicates the measuring value type used in
PRIMARY_VALUE. Valid range are as follows;
100: mass flow
101: volumetric flow
102: average mass flow
103: average volumetric flow
65535: other
Factory default is 101: volumetric flow.
ALARM_PERFORM
(1) Overview
This parameter masks Alarm/Warning. By
setting "0" to each bit, corresponding
Alarm/Warning are cleared. When masked the
corresponding bit of DEVICE_STATUS
becomes OFF and no alarm is displayed on
LCD, and also becomes out of scope of
Primary value status, ED_ERROR setting.
(2) Bit mapping (0 :MASK, 1 :NON MASK)
bit
categorize
Alarm
0 Process 30:Sig Overflow
1 Alarms 31: Empty Pipe
2
Warning
33:Adhesion Alm
3
4
80:Adhesion Wng
82:Auto Zero Wng
defalt
1
1
0
0
1
5
85:Flow Vel Over 1
6 ~ 15 Not used in AXF
0
23 ~ 31 Not used in AXF
0
16 AI 42:AI FB O/S Mode
110:AI Lo Lo Alm
111:AI Hi Hi Alm
130:AI Non-Schedule
141:AI Sim. Enabled
150:AI FB Man Mode
1
17 IT1 43:IT1 FB O/S Mode
131:IT1 Non-Schedule
151:IT1 FB Man Mode
120:IT1 Low Clock Per
0
18 IT2 44:IT2 FB O/S Mode
132:IT2 Non-Schedule
152:IT2 FB Man Mode
121:IT2 Low Clock Per
0
19 DI1 45:DI1 FB O/S Mode
133:DI1 Non-Schedule
142:DI1 Sim. Enabled
153:DI1 FB Man Mode
0
20 DI2 46:DI2 FB O/S Mode
134:DI2 Non-Schedule
143:DI2 Sim. Enabled
154:DI2 FB Man Mode
0
21 AR 47:AR FB O/S Mode
135:AR Non-Schedule
155:AR FB Man Mode
122:AR Range Set Err
0
22 PID 42:PID FB O/S Mode
112:PID Lo Lo Alm
113:PID Hi Hi Alm
136:PID Non-Schedule
156:PID FB Man Mode
160:PID FB Bypass Mode
0
T0502.eps
