IM 01E20F02-01E
9-2
9. GENERAL SPECIFICATIONS
MODEL AND SUFFIX CODE
Integral Flowmeter AXF:
AXFⵧⵧⵧⵧ-Fⵧⵧⵧⵧⵧ-ⵧⵧⵧⵧ-ⵧⵧⵧ/ⵧ
Remote Converter AXFA14:
AXFA14ⵧ-Fⵧ-ⵧⵧ/ⵧ
(Note1) “F” following the first dash indicates that the output is
digital communication compliant with the FOUNDATION
fieldbus protocol.
9.2 OPTIONAL SPECIFICATIONS
For options other than below, refer to IM 01E20D01-01E and IM 01E20C02-01E
(Optional codes C1, C2, C3, EM, G11 and G13 are unable to select).
T04.eps
PID control Function
Based on Fieldbus Foundation Specification (FF-883)
Download class: Class1
Description CodeItem
LC1
EE
PID Function
Software download function
<Factory Setting>
As specified in order
In case of different Software Tag (PD_TAG) is required from Tag Number
above in the amplifier memory, specify at Software Tag. Default (FT2001)
be set for PD_TAG unless otherwise both Tag Number and Software Tag
specified in order.
'0xF4' unless otherwise specified in order
'BASIC' or as specified
Always 'Direct'
FROWRATE SPAN of flowtube order information be set in XD_SCALE.
Lower Range Value be always zero.
Refer to Table below.
'OUT_SCALE' always be the same as 'XD_SCALE'.
Tag Number (Name Plate and/or stainless steel tag plate)
Software Tag (PD_TAG)
Node Address
Operation Function Class
Output Mode (L_TYPE)
Calibration Range (XD_SCALE) Lower/Higher Range Value
Calibration Range Unit
Output Scale (OUT_SCALE) Lower/Higher Range Value
T05.EPS
To Next Page
