IM 01E20F02-01E
8-4
8. PARAMETER LISTS
8.2 Transducer Block
T0802-1.EPS
Write
Mode
Explanation
Factory
Default
Relative
Index
Parameter NameIndex
Information on this block such as Block Tag, DD Revision,
Execution Time etc.
The revision level of the static data associated with the function
block. The revision value will be incremented each time a static
parameter value in the block is changed.
The user description of the intended application of the block.
The strategy field can be used to identify grouping of blocks.
This data is not checked or processed by the block.
The identification number of the plant unit. This information may
be used in the host for sorting alarms, etc.
The actual, target, permitted, and normal modes of the block.
This parameter reflects the error status associated with
hardware or software components associated with a block.
It is a bit string, so that multiple errors may be shown.
This alert is generated by any change to the static data.
The block alarm is used for all configuration, hardware,
connection failure or system problems in the block. The cause
of the alert is entered in the subcode field. The first alert to
become active will set the Active status in the Status attribute.
A directory that specifies the number and starting indices of the
device.
Identifies the device type, which is "Standard Flow with
Calibration" for the AXF.
Indicates the error code of the error of the highest priority from
among the errors currently occurring in the transducer block.
0=No failure, 20=Electronics failure, 21=Mechanical failure,
22=I/O failure
A directory that specifies the number, starting indices, and DD
Item IDs of the data collections in each transducer with a
transducer block.
The type of measurement represented by the primary value.
Followings are available for the AXF: 100: mass flow,
101: volumetric flow, 102: average mass flow, 103: average
volumetric flow
Indicates the flow rate.
Indicates the flow range. These values are converted the value
of SENSOR_RANGE by the unit of XD_SCALE and the data of
LINE_SIZE.
The highest calibrated value. To set within the range of
SENSOR_RANGE.
The lowest calibrated value. To set within the range of
SENSOR_RANGE.
The minimum calibration span value allowed.
The engineering unit for the calibrated values. Refer to Table in
5.4.1 for the units available.
Indicates the sensor type, which is "Electromagnetic" for the AXF.
The high and low range limit values, engineering units code and
the number of digits to the right of the decimal point for the sensor.
Serial number.
The method of the last sensor calibration.
100=volumetric
101=static weigh
102=dynamic weigh
255=other
Sets/indicates the location of the last sensor calibration.
Sets/indicates the date of the last sensor calibration.
Sets/indicates the name of the person responsible for the last
sensor calibration.
1 2001 ST_REV 0
3 2003 STRATEGY 1
4 2004 ALERT_KEY 1 Auto
5 2005 MODE_BLK
6 2006 BLOCK_ERR 0x0000
7 2007 UPDATE_EVT
8 2008 BLOCK_ALM
9 2009
10 2010 104:
Standard Flow with
Calibration
13 2013 O/S
14 2014 PRIMARY_VALUE -
15 2015
16 2016 CAL_POINT_HI 2 O/S
17 2017 CAL_POINT_LO 0 O/S
18 2018 CAL_MIN_SPAN 0.1
22 2022 SENSOR_SN Spaces
23 2023 101: O/S
19 2019 CAL_UNIT 1061:m/s O/S
20 2020 SENSOR_TYPE 102 O/S
21 2021 SENSOR_RANGE
24 2024 SENSOR_CAL_LOC Yokogawa O/S
25 2025 SENSOR_CAL_DATE 0, 0, 0, 0, 0, 0 O/S
26 2026 SENSOR_CAL_WHO Yokogawa O/S
11 2011 XD_ERROR 0
12 2012
2 2002 TAG_DESC
0 2000 BLOCK_HEADER
TRANSDUCER_
DIRECTORY
TRANSDUCER_
TYPE
COLLECTION_
DIRECTORY
PRIMARY_VALUE_
RANGE
PRIMARY_VALUE_
TYPE
SENSOR_CAL_
METHOD
101:Volumetric flow
32 space
characters
Auto
Static weigh
