8. PARAMETER LISTS
8.4 Dl Function Block
T0804-1.EPS
Write
Mode
Explanation
Factory
Default
Relative
Index
Parameter Name
Index
DI1
Index
DI2
Information on this block such as Block Tag, DD Revision,
Execution Time etc.
The revision level of the static data of the DI block. The
value of this parameter is incremented each time a static
parameter value is changed. Valid range is 0 to 65535.
The user description of the intended application of the block
Used by an upper-level system to identify grouping of the
block. Not checked or processed by the block. Valid range
is 0 to 65535.
The identification number of the plant unit. This information
may be used in the host for sorting alarms, etc.
The actual, target, permitted and normal modes of the block.
Indicates the error statuses related to the block itself.
The primary discrete value (or process value) for execution
of the block's functions.
Indicates the value and status of block's output.
Allows use of values manually set instead of the limit switch
input from the transducer block. When Disable is set for
this value, the block reflects the actual input value and
status. 1: Disabled, 2: Active
Not used in AXF.
Not used in AXF.
Option to control access from the host computer and local
control panel to tuning and alarm parameters. Before write
access to a parameter, set the GRANT bit in this parameter
to have the operation right to be granted. Then after write
access, check the DENY bit in this parameter. If the write
access is successfully, it is not ON.
Sets the block input/output options. The AXF supports only
0: Invert (LSB).
Defines block actions depending on block status conditions.
For DI blocks of the AXF, 3: Propagate fault Forward,
8: Uncertain if Man mode are supported.
The channel number of the transducer block's logical
hardware channel connected to this block. Valid range is
2: LIMSW_1, 3: LIMSW_2, 4: SWITCH_1, 5: SWITCH_2
Sets the time constant of damping for PV_D.
The status of the limit switch signal transferred from the
transducer block.
1 6001 6101 ST_REV 0
0 6000 6100 Block Header O/S
3 6003 6103 STRATEGY 1 Auto
4 6004 6104 ALERT_KEY 1 Auto
5 6005 6105 MODE_BLK
6 6006 6106 BLOCK_ERR
7 6007 6107 PV_D
8 6008 6108 OUT_D
9 6009 6109 SIMULATE_D Auto
10 6010 6110 XD_STATE 0
13 6013 6113 IO_OPTS 0x0000 O/S
14 6014 6114 STATUS_OPTS 0x0000 O/S
15 6015 6115 CHANNEL O/S
16 6016 6116 PV_FTIME 0 Auto
17 6017 6117 FIELD_VAL_D
Shows the content of an update event (a change to the
setpoint) upon occurrence.
18 6018 6118 UPDATE_EVT -
Shows the contents of a block alarm upon occurrence 19 6019 6119 BLOCK_ALM -
Indicates the current alarm statuses. 20 6020 6120 ALARM_SUM 0x0000
Selects whether alarms associated with the block will be
automatically acknowledged.
21 6021 6121 ACK_OPTION 0xFFFF
Sets the alarm priority level. 22 6022 6122 DISC_PRI 0
Indicates the status of the input for the discrete alarm. 23 6023 6123 DISC_LIM 0
Indicates the status of the related to the discrete alarm. 24 6024 6124 DISC_ALM
11 6011 6111 OUT_STATE 0
12 6012 6112 GRANT_DENY Auto
2 6002 6102 TAG_DESC spaces Auto
DI1: TAG="DI1"
DI2: TAG="DI2"
DI1: 2
DI2: 3
