7. DEVICE INFORMATION
7.2 Status of each parameter in
failure mode
Following tables summarize the value of AXF
parameters and LCD display indicates an Alarm.
Table 7.9 Alarm Summary
T0708.EPS
10:uP Fault 200 Other Hold BAD:Device Failure
11:EEPROM Fault 199 Other Hold BAD:Device Failure
12:A/D (H) Fault 198 Other Hold BAD:Device Failure
13:A/D (L) Fault 197 Other Hold BAD:Device Failure
14:A/D (Z) Fault 196 Other Hold BAD:Device Failure
15:Coil Open 195 Other Hold BAD:Sensor Failure
16:EEPROM Dflt 194 Other Hold BAD:Device Failure
100:Comm uP Fault 190 Other Variable BAD:Device Failure
101:Comm EEPROM Fault 189 Other Variable BAD:Device Failure
102:IT1 Not Saved -
103:IT2 Not Saved -
104:Comm Error1 188 Other Variable BAD:Device Failure
105:Comm Error2 187 Other Variable BAD:Device Failure
106:DL Incomplete -
107:Download Fail -
108:Not Ready -
30:Sig Overflow 170 Other Hold BAD:Sensor Failure
31:Empty Pipe 169 Other Hold BAD:Sensor Failure
33:Adhesion Alm 167 Other Hold BAD:Sensor Failure
110:AI Lo Lo Alm -
111:AI Hi Hi Alm -
112:PID Lo Lo Alm -
113:PID Hi Hi Alm -
40:RS O/S Mode BAD:Non-specific
41:TB O/S Mode Out of BAD:Out of Service
Service
42:AI FB O/S Mode -
43:IT1 FB O/S Mode -
44:IT2 FB O/S Mode -
45:DI1 FB O/S Mode -
46:DI2 FB O/S Mode -
47:AR FB O/S Mode -
48:PID FB O/S Mode -
50:Span > 10m/s 160 Other Hold BAD:Configuration
Error
51:Span < 0.1m/s 159 Other Hold BAD:Configuration
Error
57:Dens Set Err 157 Other Hold BAD:Configuration
Error
71:Meas Mod Set 156 Other Hold BAD:Configuration
Error
72:Size Set Err 155 Other Hold BAD:Configuration
Error
73:Adh Set Err 154 Other Hold BAD:Configuration
Error
120:IT1 Clock Per Err -
121:IT2 Clock Per Err -
122:AR Range Set Err -
Category
Alarm
XD_
ERROR
(Value)
BLOCK_
ERROR
Primary
Value
Primary Value
Status
System
Alarms
Process
Alarms
O/S
Mode
Alarms
Setting
Alarms
80:Adhesion Wng 150 Other Uncertain:Sensor
Conversion not
Accurate
82:Auto Zero Wng 148 Other Uncertain:Sensor
Conversion not
Accurate
84:Disp Over Wng -
85:Flow Vel Over 147 Other Uncertain: Engineering
Unit Range
Violation
130:AI Non-Schedule -
131:IT1 Non-Schedule -
132:IT2 Non-Schedule -
133:DI1 Non-Schedule -
134:DI2 Non-Schedule -
135:AR Non-Schedule -
136:PID Non-Schedule -
140:Sim. Jmpr On -
141:AI Sim. Enabled -
142:DI1 Sim. Enabled -
143:DI2 Sim. Enabled -
150:AI FB Man Mode -
151:IT1 FB Man Mode -
152:IT2 FB Man Mode -
153:DI1 FB Man Mode -
154:DI2 FB Man Mode -
155:AR FB Man Mode -
156:PID FB Man Mode -
160:PID FB Bypass Mode -
Category
Alarm
XD_
ERROR
(Value)
BLOCK_
ERROR
Primary
Value
Primary Value
Status
Warning
