IM 01E20F02-01E
5-6
5. EXPLANATION OF BASIC ITEMS
Table 5.4.1 Unit Codes
d
L
Ml/h (65521)
kL/h (1519)
L/h (1353)
Ml/min (65520)
kL/min (1518)
L/min (1352)
kL/s (65522)
L/s (1351)
m3
m3/d (1350) m3/ h (1349) m3/min (1348) m3/s (1347)
cm3
cm3/d (1514) cm3/h (1513) cm3/min (1512) cm3/s (1511)
m
---
m/s (1061)
t
t/d (1329) t/h (1328) t/min (1327) t/s (1326)
kg
kg/d(1325) kg/h (1324) kg/min (1323) kg/s (1322)
g
g/d (1321) g/h (1320) g/min (1319) g/s (1318)
CF
ft3/d (1359) CFH (1358) CFM (1357) CFS (1356)
Mgal (US)/d (1366)
kgal (US)/d (1462)
gal (US)/d (1365)
mgal (US)/d (1461)
Mgal (US)/h (1459)
kgal (US)/h (1458)
gal (US)/h (1364)
mgal (US)/h (1457)
Mgal (US)/min (1455)
kgal (US)/min (1454)
GPM (1363)
mgal (US)/min (1453)
Mgal (US)/s (1451)
kgal (US)/s (1450)
gal (US)/s (1362)
mgal (US)/s (1449)
kbbl (US Oil)/d (1493)
bbl (US Oil)/d (1374)
mbbl (US Oil)/d (1492)
bbl (US Oil)/d (1491)
kbbl (US Oil)/h (1489)
bbl (US Oil)/h (1373)
mbbl (US Oil)/h (1488)
bbl (US Oil)/h (1487)
kbbl (US Oil)/min (1485)
bbl (US Oil)/min (1372)
mbbl (US Oil)/min (1484)
bbl (US Oil)/min (1483)
kbbl (US Oil)/s (1481)
bbl (US Oil)/s (1371)
mbbl (US Oil)/s (1480)
bbl (US Oil)/s (1479)
kbbl (US Beer)/d (65525)
bbl (US Beer)/d (65529)
mbbl (US Beer)/d (65533)
kbbl (US Beer)/h (65524)
bbl (US Beer)/h (65528)
mbbl (US Beer)/h (65532)
bbl (US Beer)/min (65527)
mbbl (US Beer)/min (65531)
bbl (US Beer)/min (65535)
bbl (US Beer)/s (65526)
mbbl (US Beer)/s(65530)
bbl (US Beer)/s
lb
lb (US)/d (1333) lb (US)/h (1332) lb (US)/min (1331) lb (US)/s (1330)
ft
-- -ft/s (1067)
Volume/
Mass unit
Time unit
min
hs
gal(US)
bbl(US Oil)
bbl(US Beer)
Ml/d (1355)
kL/d (1520)
L/d (1354)
T0504.eps
OUT_SCALE:
Set the range of output (from 0% to 100%). In the case
of AXF, OUT_SCALE is always the same setting as
XD_SCALE.
L_TYPE:
L_TYPE is always selected as "Direct".
(Note) "Indirect" also can be set.
PV_FTIME:
Sets the time constant of the damping function within
AI block (primary delay) in seconds.
For normal magmeter’s damping setting, set by
PRIMARY_VALUE_FTIME of transducer block
instead of setting AI function block’s PV_FTIME.
To Next Page
