8. PARAMETER LISTS
T0802-5.EPS
Write
Mode
Explanation
Factory
Default
Relative
Index
Parameter NameIndex
Block Alarm status is shown by this parameter.
Valid range is bit 0: Discrete alm, bit7: Block alarm
(only bit 0 and bit 7 are effective).
Initial value is
Current: 0, Unacknowledged: 0, Unreported: 0,
Disable: 0X0000 (all alarms are enable).
Selects whether or not the adhesion diagnostic function will be
carried out. (If the judgment value for Level 3 exceeds, a warning
is displayed; and if the value for level 4 exceeds, an alarm is
displayed. Valid range is
1: No, 2: Yes
This parameter is used in order to set the resistance value for
judgment of Level 1. Valid range is 0.0 to 100.00 M Ohm
This parameter is used in order to set the resistance value for
judgment of Level 2.Valid range is 0.0 to 100.00 M Ohm
This parameter is used in order to set the resistance value for
judgment of Level 3.Valid range is 0.0 to 100.00 M Ohm
This parameter is used in order to set the resistance value for
judgment of Level 4.Valid range is 0.0 to 100.00 M Ohm
This parameter displays the value measured using the adhesion
diagnostic function. Valid range is 0.0 to 1000.00 M Ohm
85 2085 ALARM_SUM
86 2086 ADHESION_CHECK 1:No O/S
87 2087 ADHESION_LEVEL1 0.10 O/S
88 2088 ADHESION_LEVEL2 0.50 O/S
89 2089 ADHESION_LEVEL3 1.00 O/S
90 2090 ADHESION_LEVEL4 3.00 O/S
91 2091 - ADH_MEASURE_
VALUE
