:CALCulate:AMARker[1|2|3|4]:FUNCtion
:INTegral:IRANge
Function Sets or queries the integration frequency range
of the specified integrated power marker.
Syntax
:CALCulate:AMARker[1|2|3|4]:FUNCtio
n:INTegral:IRANge<wsp><NRf>[Hz]
:CALCulate:AMARker[1|2|3|4]:FUNCtio
n:INTegral:IRANge?
[1|2|3|4]: Advanced marker number
<NRf> = Integration frequency range [Hz]
Example
:CALCULATE:AMARKER:FUNCTION:INTEGRA
L:IRANge 40GHz
:CALCULATE:AMARKER:FUNCTION:INTEGRA
L:IRANge? -> 4.00000000E+010
Description • An execution error will occur if the specified
advanced marker has not been assigned or is
not an integrated power marker.
• A query error will occur if the specified
advanced marker has not been assigned or is
not an integrated power marker.
• If the advanced marker number is not
specified, advanced marker 1 will be used.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
:CALCulate:AMARker[1|2|3|4]:FUNCtion
:INTegral:RESult?
Function Queries the integration value of the specified
integrated power marker.
Syntax
:CALCulate:AMARker[1|2|3|4]:FUNCtio
n:INTegral:RESult?
[1|2|3|4]: Advanced marker number
Example
:CALCULATE:AMARKER:FUNCTION:INTEGRA
L:RESULT? -> -1.00000000E+001
Description • The unit of the returned marker level depends
on the Y-axis unit of the assigned marker trace.
• A query error will occur if the specified
advanced marker has not been assigned or is
not an integrated power marker.
• If the advanced marker number is not
specified, advanced marker 1 will be used.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
:CALCulate:AMARker[1|2|3|4]:FUNCtion
:INTegral[:STATe]
Function Moves the specified integrated power marker to
the center of the marker trace.
Also queries the status of the specified
integrated power marker.
Syntax
:CALCulate:AMARker[1|2|3|4]:FUNCtion:I
NTegral[:STATe]<wsp>OFF|ON|0|1
:CALCulate:AMARker[1|2|3|4]:FUNCtion
:INTegral[:STATe]?
[1|2|3|4]: Advanced marker number
Response 0 = Off, 1 = On
Example
:CALCULATE:AMARKER:FUNCTION:INTEGR
AL ON
:CALCULATE:AMARKER:FUNCTION:INTEGR
AL? -> 1
Description • If an integrated power marker
is assigned, moving markers
(:CALCulate:AMARker[1|2|3|4][:STATe]) and
power spectral density markers (:CALCulate:
AMARker[1|2|3|4]:FUNCtion:PDENsity|:NOIS
e[:STATe]) will be set to off.
• If this command with the parameter set to
OFF is specified on an advanced marker
that has been assigned to integrated power
marker, the advanced marker will change to a
moving marker.
If the advanced marker has not been
assigned, using this command with the
parameter set to OFF will leave the advanced
marker unassigned.
• If the advanced marker number is not
specified, advanced marker 1 will be used.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
7.6 Instrument-Specific Commands
