4.3 Setting Up RS-232
Procedure
Selecting the Communication Interface
1.
Press SYSTEM. The system setting menu is displayed.
2.
Press the MORE1/4 soft key. The communication interface setting menu is
displayed.
3.
Press the REMOTE INTERFACE soft key. The setting menu for the interface to
be used is displayed.
4.
Press the RS-232 soft key to specify RS-232 as the communication interface.
Setting the Baud Rate
5.
Press the RS-232 SETTING soft key. The RS-232 setting menu is displayed.
6.
Press the BAUD RATE soft key. The baud rate setting menu is displayed.
7.
Press the soft key corresponding to the desired baud rate setting. The baud rate
is set.
To Next Page
