AQ6317 Status Byte
The status byte of AQ6317-compatible mode operates like the status byte in the AQ6317.
Refer to the manuals for the AQ6317 series for the details of GP-IB.
Bit Function and Setting Condition Clear Timing
Bit 7 0
Bit 6 Send an SRQ signal. • Upon execution of serial polling
• Upon receipt of DCL or SDC
Bit 5 When receiving data exceeding the receive • Upon execution of serial polling
buffer capacity of 512 byte “1” is set. • Upon receipt of DCL or SDC
• At a start of measurement
Bit 4 0
Bit 3 When a command data error occurs, set “1”. • Upon receipt of DCL or SDC
• Upon execution of serial polling
• At a start of measurement
Bit 2 Warning error (including errors upon • When the warning error display
execution of a Program) occurs, set “1”. disappears
For the contents of the warning its number • Upon execution of serial polling
can be output • Upon receipt of DCL or SDC
• At a start of measurement
Bit 1 When the execution of a copy or program • Upon execution of serial polling
terminates, set “1”. • Upon receipt of DCL or SDC
• At a start of measurement
Bit 0 After sweep finishes, “1” is set. • Upon execution of serial polling
• Upon receipt of DCL or SDC
• At a start of measurement
