GP-IB Interface (GP-IB1 Port)
1
2
3
4
5
6
7
8
App
Index
Sample Program 2
Save an image of the instrument's screen to a BMP file, then use a file transfer command
to load the file onto the PC. Save the image on the PC under the file name, "C:\test.
bmp".
Const BOARD_ID = 0 'GP-IB Interface card Address
Const osa = 1 'OSA GP-IB Address
Private Sub Command1_Click()
Dim intAddrList(31) As Integer
Dim intData As Integer
Dim lngDataSize As Long
Dim strData As String
Dim intI As Integer
Dim byteData() As Byte
Dim byteSaveData() As Byte
Dim lngL As Long
'----- GP-IB Interface setting
' send IFC
Call SendIFC(BOARD_ID)
' assert th REN GPIB line
intAddrList(0) = NOADDR
Call EnableRemote(BOARD_ID, intAddrList())
' GPIB time out setting
Call ibtmo(BOARD_ID, T30s) 'Time out = 30sec
'----- send command to OSA
Call SendGPIB(osa, "CFORM1") ' Command mode set(AQ637X mode)
Call SendGPIB(osa, ":mmem:stor:grap color,bmp,""test"",int")
' Save bmp file to internal memory
Call SendGPIB(osa, ":mmem:data? ""test.bmp"",int")
' get file data from OSA
lngDataSize = RecieveBinaryGPIB(osa, byteData())
' Recieve binary block data
If byteData(0) <> Asc("#") Then ' check first data
MsgBox "Data format error"
Exit Sub
End If
'----- calculate data size
intData = byteData(1) - Asc("0")
strData = ""
For intI = 1 To intData
strData = strData + Chr(byteData(intI + 1))
Next intI
lngDataSize = Val(strData) ' data size
'----- make save data
ReDim byteSaveData(lngDataSize)
For lngL = 0 To lngDataSize - 1
byteSaveData(lngL) = byteData(lngL + intData + 2)
Next lngL
'----- save data to file
Open "c:\test.bmp" For Binary As #1
Put #1, , byteSaveData
Close #1
'----- Disconnect
Call EnableLocal(BOARD_ID, intAddrList())
MsgBox "Complete"
End Sub
2.6 Sample Program

YOKOGAWA AQ6370C Specifications

General

Wavelength Range	600 to 1700 nm
Wavelength Accuracy (1520 to 1620 nm)	±0.01 nm
Level Accuracy	±0.5 dB
Polarization Dependency	±0.05 dB
Measurement Speed	0.2 sec (100 nm span)
Wavelength Accuracy	±0.02 nm
Dynamic Range	78 dB (peak ±1 nm)
Sensitivity	-90 dBm
Input Power Range	+20 to -80 dBm
Sweep Time	0.2 to 2000 s
Display	10.4-inch color LCD
Interface	Ethernet, USB
Light Source	Built-in calibration source
Dimensions (W x H x D)	426 mm

Summary

Safety Precautions

Chapter 1 Remote Control Functions

1.1 Remote Interfaces

Describes the various types of communication interfaces available for remote control.

Chapter 2 GP-IB Interface (GP-IB1 Port)

2.1 Connecting via GP-IB

Details the physical connection process for the GP-IB1 port using a GP-IB cable.

2.2 GP-IB Interface Function

2.4 Setting the GP-IB Address

Chapter 3 Ethernet Interface

3.1 Connecting via Ethernet

Explains how to connect the instrument to a LAN using the Ethernet interface from a PC.

3.2 Setting Up Ethernet

Chapter 4 Serial (RS-232) Interface

4.1 Connecting via the Serial (RS-232) Interface

Describes the serial interface connection, its functions, specifications, and physical connection.

4.2 Remote Control Using Commands

4.3 Setting Up RS-232

Chapter 5 GP-IB Interface (GP-IB2 Port )

5.1 Connecting via GP-IB2

Details the physical connection process for the GP-IB2 port, used for controlling external instruments.

5.3 Setting the GP-IB Address

Chapter 6 Status Registers

6.1 Status Registers

Provides an overview of the instrument's status registers, including types defined by IEEE 488-2 and SCPI.

6.2 Status Byte Registers

Chapter 7 Remote Commands

7.1 Rules of Syntax and Command Types

Explains the syntax rules and classification of remote commands used for instrument control.

7.2 Table of Correspondence between Soft Keys and Remote Commands

Lists remote commands corresponding to instrument soft keys for various settings.

7.3 ANALYSIS Setting Parameters

7.5 Common Commands

7.6 Instrument-Specific Commands

Details commands specific to instrument functions, organized by subsystem.

Chapter 8 Program Function

8.1 Editing a Program

Guides the user through the process of creating, editing, and managing programs on the instrument.

8.2 Executing a Program

Explains the two methods for executing programs: specifying and executing, or assigning to a soft key.

8.3 Program Function Commands

8.4 Controlling an External Instrument with the Program Function
