Notations Used in the Procedural Explanations
On pages that describe the operating procedures in each chapter, the following notations
are used to distinguish the procedure from their explanations.
Procedure
This subsection contains the operating procedure used to carry out
the function described in the current section. The procedures are
written with inexperienced users in mind; experienced users may not
need to carry out all the steps.
Explanation
This subsection describes the setup parameters and the limitations
on the procedures.
Terms Used in Explanations of Procedures
Panel Keys and Soft Keys
Bold characters used in the procedural explanations indicate characters that are marked on the
panel keys or the characters of the soft keys displayed on the screen menu.
SHIFT+Panel Key
SHIFT+key means you will press the SHIFT key to turn it ON and then press the panel key. The
setup menu marked in purple below the panel key that you pressed appears on screen.
Units
k Denotes 1000. Example: 12 kg, 100 kHz
K Denotes 1024. Example: 459 KB (file size)
Conventions Used in This Manual
