YOKOGAWA AXFA14G User Manual

<3. Installation>
19
IM 01E20A01-01EN
Table3.3.10 CenteringDeviceIdentication(AXFStandardModels,PFA/PolyurethaneRubber/NaturalSoftRubber/EPDM
Rubber lining)
Flange ratings
Size
mm (inch)
JIS ANSI DIN JPI
10K 20K F12 (75M) Class 150 Class 300 PN10 PN16 PN40 Class 150
50 (2.0) B B — B F — — F B
65 (2.5) B B — B G — F — —
80 (3.0) B F H F C — G — F
100 (4.0) B F H C H — F — C
125 (5.0) B C C G D — F — —
150 (6.0) C D D C E — C — C
200 (8.0) C D D D E C C — D
250 (10) C — D N — C C — N
300 (12) C — D P — C C — P
*:Eachcenteringdeviceisengravedwithacharacterasidentication.
Table3.3.11 CenteringDeviceIdentication(AXFStandardModels,Ceramicslining)
Flange ratings
Size
mm (inch)
JIS ANSI DIN
10K 20K F12 (75M) Class 150 Class 300 PN10 PN16 PN40
50 (2.0) B B — B F — — F
80 (3.0) B F H F C — G —
100 (4.0) B F H C H — F —
150 (6.0) B C G B D — B —
200 (8.0) B C C G J B B —
*:Eachcenteringdeviceisengravedwithacharacterasidentication.
Table3.3.12 CenteringDeviceIdentication(ReplacementModels,PFA/PolyurethaneRubberlining)
Flange ratings
Size
mm (inch)
JIS ANSI DIN
10K 20K F12(75M) Class 150 Class 300 PN10 PN16 PN40
50 (2.0) B B — B F — — F
80 (3.0) B F H F C — G —
100 (4.0) B F H C H — F —
150 (6.0) C D
D
C E — C —
200 (8.0) C D D D E C C —
*:Eachcenteringdeviceisengravedwithacharacterasidentication.
