YOKOGAWA AXFA14G User Manual

<1. Introduction>
2
IM 01E20A01-01EN
IMPORTANT
An IMPORTANT sign denotes that attention is
required to avoid damage to the instrument or system
failure.
NOTE
A NOTE sign denotes information necessary for
essential understanding of operation and features.
Protective grounding terminal
Functional grounding terminal
(This terminal should not be used as a
protective grounding terminal.)
Alternating current
Direct current
Caution
This symbol indicates that the operator must
refer to an explanation in the user’s manual
in order to avoid the risk of injury or death of
personnel or damage to the instrument.
 Regarding This User’s Manual
• This manual should be provided to the end user.
• Before use, read this manual thoroughly to
comprehend its contents.
• The contents of this manual may be changed without
prior notice.
• All rights are reserved. No part of this manual may be
reproduced in any form without Yokogawa’s written
permission.
• Yokogawa makes no warranty of any kind with regard
to this material, including, but not limited to, implied
warranties of merchantability and suitability for a
particular purpose.
• All reasonable effort has been made to ensure the
accuracy of the contents of this manual. However, if
any errors or omissions are found, inform Yokogawa.
• Yokogawa assumes no responsibilities for this
product except as stated in the warranty.
• Note that this user’s manual may not be revised for
anyspecicationchanges,constructionchangesor
operating part changes that are not considered to
affect function or performance.
• If the customer or any third party is harmed by the use
of this product, Yokogawa assumes no responsibility
for any such harm owing to any defects in the product
which were not predictable, or for any indirect
damages.
 Trademarks:
• All the brands or names of Yokogawa Electric’s
products used in this manual are either trademarks
or registered trademarks of Yokogawa Electric
Corporation.
• All other company and product names mentioned
in this manual are trade names, trademarks or
registered trademarks of their respective companies.
• In this manual, trademarks or registered trademarks
are not marked with ™ or ®.
1.1 Using the Magnetic
Flowmeter Safely
(1) Installation
WARNING
• Installationofthemagneticowmetermustbe
performed by expert engineer or skilled personnel.
No operator shall be permitted to perform
procedures relating to installation.
• Themagneticowmetermustbeinstalledwithin
thespecicationconditions.
• Themagneticowmeterisaheavyinstrument.
Be careful that no damage is caused to personnel
through accidentally dropping it, or by exerting
excessiveforceonthemagneticowmeter.When
movingthemagneticowmeter,alwaysusea
trolley and have at least two people carry it.
• Whenthemagneticowmeterisprocessinghot
uids,theinstrumentitselfmaybecomeextremely
hot.Takesufcientcarenottogetburnt.
• Wheretheuidbeingprocessedisatoxic
substance,avoidcontactwiththeuidand
avoid inhaling any residual gas, even after the
instrument has been taken off the piping line for
maintenance and so forth.
• Do not apply excessive weight, for example, a
personsteppingonthemagneticowmeter.
• All procedures relating to installation must comply
with the electrical code of the country where it is
used.
