8.2 Parameter List (BRAIN)
Item
Name
R/W
(*3)
Data range
Units
Position of
decimal point
Default value (*):
Indicated item
Description
Display unit (BRAIN) Display unit/BRAIN
A00 Display
(DISPLAY)
A10 FR
(FLOW RATE (%))
R -110.0 to 110.0 % 1 For Display Mode only
A20 FR
(FLOW RATE)
R -999999 to 999999 B21/B22
(C40/C41)
0 to 3 For Display Mode only
A21 FR
(FLW RATE (mA))
R 2.400 to 21.600 mA 3 For Display Mode only
A30 FTL
(TOTAL)
R 0 to 99999999 B30
(D10)
0 to 7 For Display Mode only
A31 RTL
(REV TOTAL)
R 0 to 99999999 B30
(D10)
0 to 7 For Display Mode only
A32 DTL
(DIF TOTAL)
R -99999999
to 99999999
B30
(D10)
0 to 7 For Display Mode only
A60 —
(SELF CHECK)
R Good
Error
See Chapter 7.
B00 Easy Setup
(EASY SETUP)
B10 Language
(LANGUAGE)
W English
Japanese
French
German
Italian
Spanish
English Selects the language used for the
display unit. Linked with H30.
B20 Flow Damping
(FLOW DAMPING)
W 0.1 to 200.0 s 1 3.0 s Sets damping time. Linked with C11.
B21 Base Flow Unit
(FLOW UNIT)
W Ml(Megaliter)
m
3
kl (Kiloliter)
l (Liter)
cm
3
m
t
kg
g
kcf
cf
mcf
Mgal (US)
kgal (US)
gal (US)
mgal (US)
kbbl (US Oil)
bbl (US Oil)
mbbl (US Oil)
ubbl (US Oil)
kbbl (US Beer)
bbl (US Beer)
mbbl (US Beer)
ubbl (US Beer)
ft
klb (US)
lb (US)
m (*) Selectsowunitsfortheowratespan.
Linked with C40.
B22 Base Time Unit
(TIME UNIT)
W /d
/h
/min
/s
/s (*) Selectstimeunitsfortheowratespan.
Linked with C41.
B23 Flow Span
(FLOW SPAN)
W 0.0001 to 32000 B21/B22
(C40/C41)
0 to 4 1 m/s (*) Setsowratespan(withunitsfromB21
and B22). Linked with C42.
B24 Flow Decimal Pnt
(FLOW DECIMAL)
W Auto
0
1
2
3
Auto (*) Selects decimal point position for the
display unit's instantaneous flow rate.
Linked with C43.
B30 Total Unit
(TOTAL UNIT)
W n Unit/P
u Unit/P
m Unit/P
Unit/P
k Unit/P
M Unit/P
Pulse/s
Pulse/s (*) Selects the flow rate unit per one pulse
as used for totalization display. Linked
with D10.
B31 Total Scale
(TOTAL SCALE)
W 0 to 32000 B30
(D10)
0 to 4 0 (*) Sets the flow rate per one pulse for the
totalization display.Linked with D11.
*3: R/W: R = Read only, W = Read and Write
Parameter Summary
8
