YOKOGAWA AXFA14G User Manual

Item
Name
R/W
(*3)
Data range
Units
Position of
decimal point
Default value (*):
Indicated item
Description
Display unit (BRAIN) Display unit/BRAIN
B32 Pulse Unit
(PULSE UNIT)
W n Unit/P
u Unit/P
m Unit/P
Unit/P
k Unit/P
M Unit/P
Pulse/s
Pulse/s (*) Selects the flow rate unit per one pulse
as used for pulse output. Linked with
E10.
B33 Pulse Scale
(PULSE SCALE)
W 0 to 32000 B32
(E10)
0 to 4 0 (*) Setstheowrateperonepulseasused
for pulse output. Linked with E11.
B40 Display Select1
(DISP SELECT1)
W Flow Rate(%)
Flow Rate
Flow Rate(mA)
Forward Total
Reverse Total
Dif Total
Flow Rate Selects content of the first line for
Display Mode. Linked with H10.
B41 Display Select2
(DISP SELECT2)
W Off
Flow Rate(%)
Flow Rate
Flow Rate(mA)
Flow Rate(Bar)
Forward Total
Reverse Total
Dif Total
Tag No
Adhesion Check
Communication
Off Selects content of the second line for
Display Mode. Linked with H11.
B42 Display Select3
(DISP SELECT3)
W Same as B41
(Display Select2)
Off Selects content of the third line for
Display Mode. Linked with H12.
B50 Auto Zero Exe
(AUTOZERO EXE)
W No Execution
Execution
No Execution Selects whether or not automatic zero
adjustment is carried out. Linked with
M10.
B60 —
(SELF CHECK)
R Good
Error
See Chapter 7.
C00 Basic Setup
(BASIC SETUP)
C10 Tag No
(TAG NO)
W ASCII 16 characters Sets Tag number up to 16 characters.
C11 Flow Damping
(FLOW DAMPING)
W 0.1 to 200.0 s 1 3.0 s Sets damping time. Linked with B20.
C20 Measure Mode
(MEASURE MODE)
W Standard DF
Enhanced DF
Standard DF Selects measurement mode for dual
frequency excitation
C21 Low MF
(LOW MF)
W 0.0100 to 3.0000 4 1.0000 (*) Sets low-frequency meter factor for
standard dual frequency excitation
C22 High MF
(HIGH MF)
W 0.0100 to 3.0000 4 1.0000 (*) Sets high-frequency meter factor for
standard dual frequency excitation
C23 Low MF(EDF)
(LOW MF(EDF))
W 0.0000 to 3.0000 4 1.0000 (*) Sets low-frequency meter factor for
enhanced dual frequency excitation
C24 High MF(EDF)
(HIGH MF(EDF))
W 0.0000 to 3.0000 4 1.0000 (*) Sets high-frequency meter factor for
enhanced dual frequency excitation
C30
(*1)
Select Flow Tube
(FLOW TUBE)
W ADMAG AXF
ADMAG
ADMAG AE
ADMAG SE
YEWMAG
Calibrator
Other
ADMAG AXF Selectstheowtube'smodelname.
Note:Select“ADMAGAXF”forADMAG
AXWowtube.
C31 Nominal Size Unit
(SIZE UNIT)
W mm
inch
mm
inch
Selects the nominal size units for the
owtube.
C32 Nominal Size
(NOMINAL SIZE)
W 0.99 to 3000.1
0.01 to 120.1
mm
inch
0 to 2 100 (*) Sets flowtube nominal size in selected
unit at C31.
*1: Applicable for AXFA11 Remote Converter.
*3: R/W: R = Read only, W = Read and Write
<8. Parameter Summary>
68
IM 01E20A01-01EN
