<10. EXPLOSION PROTECTED TYPE INSTRUMENT>
10-2
IM 01F06F00-01EN
Ambient Temperature:
-40 to +60°C (Integral Type)
-50 to +80[+78]°C (Remote Type Detector)
-40 to +80°C (Remote Type Converter)
(Option /LT below -29°C, [ ] Option /MV at T6)
Electrical Data:
Entity Ui = 24 V, Ii = 250 mA, Pi = 1.2 W,
Ci = 3.52 nF, Li = 0 mH
FISCO(IIC) Ui = 17.5 V, Ii = 500 mA, Pi = 5.5 W,
Ci = 3.52 nF, Li = 0 mH
Connect sensor circuit of DYA and DY-N (/HT)
(Integral Type)
Temperature Class Process Temperature
T4 ≤ +135°C
T3 ≤ +200°C
T2 ≤ +250°C
T1 ≤ +250°C
(Remote Type Detector)
Temperature Class Process Temperature*
T6 ≤ +84/[+78]°C
T5 ≤ +100°C
T4 ≤ +135°C
T3 ≤ +199°C
T2 ≤ +299/[+288]°C
T1 ≤ +449/[+438]°C
*: Use /HT option above +250°C, use /LT option below -29 °C, [ ]
for /MV option.
Specicconditionsofuse
• Electrostatic charges on the non-metallic parts
(excluding glass parts) or coated parts of the
equipment shall be avoided.
• The dielectric strength of at least 500 V a.c.
r.m.s. between the intrinsically safe circuits and
the enclosure of the ow meter or the converter
is limited only by the overvoltage protection.
• Because the enclosures of the ow meters
and the ow converter are made of aluminium
alloy, when used in an potentially explosive
atmosphere requiring apparatus of equipment
categoly 1 G, they must be installed so, that
even in the event of rare incidents, an ignition
source due to impact of friction between the
enclosure and iron/steel is excluded.
•IntrinsicallySafeExic
Applicable Standard:
EN 60079-0:2012+A11:2013
EN 60079-11:2012
Type of Protection:
Ex ic IIC T4…T1 Gc (Integral Type)
Ex ic IIC T6…T1 Gc (Remote Type Detector)
Ex ic IIC T5…T4 Gc (Remort Type Converter)
Group: II
Category: 3 G
Enclosure:IP66/67
Overvoltage Category:I
Ambient Temperature:
-40 to +60°C (Integral Type)
-50 to +80 [+79]°C (Remote Type Detector)
(Option /LT below -29°C, [ ] for Option /MV at T6)
-40 to +80°C (Remote Type Converter)
(Integral Type)
Temperature Class Process Temperature
T4 -40°C to +135°C
T3 -40°C to +199°C
T2 -40°C to +250°C
T1 –40°C to +250°C
(Remote Type Detector)
Temperature Class Process Temperature
T6 –196°C to +84/[+79]°C
T5 –196°C to +100°C
T4 –196°C to +135°C
T3 –196°C to +199°C
T2 –196°C to +299/[+289]°C
T1 –196°C to +449/[+439]°C
*: Use /HT option above +250°C, use /LT option below -29°C, [ ]
for /MV option.
Electrical data:
Supply and Output Circuit (SUPPLY + and –);
FISCO Field Device
Entity Concept:
Maximum Input Voltage Ui: 32Vdc
Internal Capacitance Ci: 3.52nF
Internal Inductance Li: 0mH
Electrical Connection: ANSI 1/2 NPT female,
ISO M20 X 1.5 female
For the connection of DYA to DY-N :
Maximum cable capacitance: 160nF
Electrical Connection: ANSI 1/2 NPT female,
ISO M20 X 1.5 female
Specicconditionsofuse
• Electrostatic charges on the non-metallic parts
(excluding glass parts) or coated parts of the
equipment shall be avoided.
• The dielectric strength of at least 500 V a.c.
r.m.s. between the intrinsically safe circuits and
the enclosure of the ow meter or the converter
is limited only by the overvoltage protection.
