YOKOGAWA digitalYEWFLO Series User Manual

<10. EXPLOSION PROTECTED TYPE INSTRUMENT>
10-13
IM 01F06F00-01EN
10.5 TIIS
Certicate:
Model
Shedder
bar Material
Integral Type Flowmeter Remote Type Detector
N (None Indicator) D (With Indicator) N (None Indicator)
DY015
DY025/R1
DY040/R2
E TC14901 TC14912 TC14923
X TC18903 TC18914 TC18925
DY025
DY040/R1
DY050/R2
E TC19504 TC19513 TC19522
X TC18904 TC18915 TC18926
DY040
DY050/R1
DY080/R2
E TC19505 TC19514 TC19523
X TC18905 TC18916 TC18927
DY050
DY080/R1
DY100/R2
E TC19506 TC19515 TC19524
X TC18906 TC18917 TC18928
DY080
DY100/R1
DY150/R2
E TC19507 TC19516 TC19525
X TC18907 TC18918 TC18929
DY100
DY150/R1
DY200/R2
E TC19508 TC19517 TC19526
X TC18908 TC18919 TC18930
DY150
DY200/R1
E TC19509 TC19518 TC19527
X TC18909 TC18920 TC18931
DY200
E TC19510 TC19519 TC19528
X TC18910 TC18921 TC18932
DY250 E TC19511 TC19520 TC19529
DY300 E TC19512 TC19521 TC19530
DY400 B TC18945 TC18955 TC18965
Model
Shedder
bar Material
Remote Type Converter
N (None Indicator) D (With Indicator)
DYA TC14934 TC14935
Integral Type Flowmeter Remote Type Flowmeter
None Indicator With Indicator Detector Converter
Construction Ex d IIC T6 ← ← ←
Flame Proof Approval ← ← ←
Amb.Temp -20°C up to +60°C ← ← ←
Rating Maximum power supply vortage: DC42V
Current Signal: DC4-20mA
Pulse Signal:
ON : 2V 200mA
OFF : 42V 4mA
Output Voltage: 30Vp-p
Output Current: 100µ Ap-p
Maximum power supply vortage:
DC42V
Current Signal: DC4-20mA
Pulse Signal:
ON : 2V 200mA
OFF : 42V 4mA
Input Signal: 30V p-p,100µ A p-p
Resistance Temp, Sensor Input:
Pt1000 at 0°C
Specied Current: less than 1mA
* In case that ambient temperature exceeds 50°C, use heat-resistant cables with maximum allowable temperature of 70°C or above.
