<APPENDIX 3. OPERATION OF EACH PARAMETER IN FAILURE MODE>
A3-12
IM 01F06F00-01EN
LCD
Display
Alarm Detail DI1 Block DI2 Block PID Block IT Block AR Block
Alarm Reset SW*
(default)
AL-62
AI1 in Man
Mode (AL-62)
Provided
(ON)
AL-63
AI1 Simulation
Active (AL-63)
Provided
(ON)
AL-64
AI1 Not
Scheduled
(AL-64)
Provided
(ON)
AL-65
AI2 in Man
Mode (AL-65)
Provided
(OFF)
AL-66
AI2 Simulation
Active (AL-66)
Provided
(OFF)
AL-67
AI2 Not
Scheduled
(AL-67)
Provided
(OFF)
AL-68
DI1 Man
Mode (AL-68)
<OUT.Status>
• Default
• STATUS_OPTS:
Uncertain if Man
mode = Active
Uncertain-Non
Specic
Provided
(OFF)
AL-69
DI1 Simulation
Active (AL-69)
<BLOCK_ERR>
Simulation Active
Provided
(OFF)
AL-70
DI1 Not
Scheduled
(AL-70)
Provided
(OFF)
AL-71
DI2 Man
Mode (AL-71)
<OUT.Status>
• Default
Good(NC)-Non
Specic
• STATUS_OPTS:
Uncertain if Man
mode = Active
Uncertain-Non
Specic
Provided
(OFF)
AL-72
DI2 Simulation
Active (AL-72)
<BLOCK_ERR>
Simulation Active
Provided
(OFF)
AL-73
DI2 Not
Scheduled
(AL-73)
Provided
(OFF)
AL-74
PID in Bypass
Mode (AL-74)
Provided
(OFF)
AL-75
PID Error 1
(AL-75)
Provided
(OFF)
AL-76
PID Error 2
(AL-76)
Provided
(OFF)
