4.1 List of Commands
Command Function page
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale?
Queries all linear scaling settings of a 4-CH module, 16-CH voltage input
module, or 16-CH temperature/voltage input module.
4-77
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:AVALue
Sets or queries the scaling coefficient A that is used during linear scaling for
a 4-CH module, 16-CH voltage input module, 16-CH temperature/voltage
input module.
4-77
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:BVALue
Sets or queries the offset value B that is used during linear scaling for a
4-CH module, 16-CH voltage input module, 16-CH temperature/voltage input
module.
4-77
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:DISPlaytype?
Queries all linear-scaling result display-mode settings of a 4-CH module, 16-
CH voltage input module, or 16-CH temperature/voltage input module.
4-78
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:DISPlaytype:DECimal
num
Sets or queries the decimal place that is used when the linear-scaling result
display mode is set to Float for a 4-CH module, 16-CH voltage input module,
or 16-CH temperature/voltage input module.
4-78
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:DISPlaytype:MODE
Sets or queries the linear-scaling result display mode of a 4-CH module, 16-
CH voltage input module, or 16-CH temperature/voltage input module.
4-78
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:DISPlaytype:SUBunit
Sets or queries the unit prefix that is used when the linear-scaling result
display mode is set to Float for a 4-CH module, 16-CH voltage input module,
or 16-CH temperature/voltage input module.
4-78
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:GETMeasure
Executes the measurement of the linear scaling P1:X or P2:X value of a
4-CH module, 16-CH voltage input module, 16-CH temperature/voltage input
module.
4-79
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:MODE
Sets or queries the linear scaling mode of a 4-CH module, 16-CH voltage
input module, or 16-CH temperature/voltage input module.
4-79
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:{P1X|P1Y|P2X|P2Y}
Sets or queries the linear scaling P1:X, P1:Y, P2:X, or P2:Y value of a 4-CH
module, 16-CH voltage input module, or 16-CH temperature/voltage input
module.
4-79
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:LSCale:UNIT
Sets or queries the linear-scaling unit string of a 4-CH module, 16-CH
voltage input module, or 16-CH temperature/voltage input module.
4-79
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:POSition
Sets or queries the vertical position of a 4-CH module, 16-CH voltage input
module, 16-CH temperature/voltage input module.
4-80
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:PROBe
Sets or queries the probe type of the 4-CH module. 4-80
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:SCALe
Sets or queries the upper and lower limits of the screen for a 4-CH module,
16-CH voltage input module, 16-CH temperature/voltage input module.
4-80
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:VARiable
Sets or queries how the vertical scale is set for a 4-CH module, 16-CH
voltage input module, 16-CH temperature/voltage input module.
4-80
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:VDIV
Sets or queries the V/div setting of a 4-CH module, 16-CH voltage input
module, 16-CH temperature/voltage input module.
4-81
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:VGAin
Sets or queries the gain setting of a 4-CH module. 4-81
:CHANnel<x1>[:VOLTage]:SCHannel
<x2>:ZOOM
Sets or queries the vertical zoom factor of a 4-CH module, 16-CH voltage
input module, 16-CH temperature/voltage input module.
4-81
:CHANnel<x>[:VOLTage]:VARiable
Sets or queries how the vertical scale is set for a module that can measure
analog voltage.
4-81
:CHANnel<x>[:VOLTage]:VDIV
Sets or queries the V/div setting of a module that can measure analog
voltage.
4-81
:CHANnel<x>[:VOLTage]:VGAin
Sets or queries the gain adjustment of a module that can measure analog
voltage.
4-81
:CHANnel<x>[:VOLTage]:ZOOM
Sets or queries the vertical zoom factor of a module that can measure
analog voltage.
4-82
CLEar Group
:CLEar
Clears traces. 4-83
COMMunicate Group
:COMMunicate?
Queries all communication settings. 4-84
:COMMunicate:HEADer
Sets or queries whether headers are attached to query responses. 4-84
:COMMunicate:LOCKout
Sets/clears local lockout. 4-84
:COMMunicate:OPSE
Sets or queries the overlap command that is used by the
*OPC
,
*OPC?
, and
*WAI
commands.
4-84
:COMMunicate:OPSR?
Queries the operation pending status register. 4-84
:COMMunicate:OVERlap
Sets or queries the commands that operate as overlap commands. 4-84
:COMMunicate:REMote
Sets or queries whether the instrument is in remote or local mode. 4-84
