Rated Time for Integrated D/A Output (Integration Rated Time)
When integrated values are output through D/A output, a rating value (the same value as the measurement
range) is continuously applied, the integrated value after the specified amount of time has elapsed is taken to
be 100%, and the D/A output at that point is 5 V. It is assumed that the change in the D/A output from 0% of the
integrated value (0 V) to 100% of the integrated value (5 V) will occur linearly over time, and the D/A output value
is determined by the ratio of the actual input level to this assumed straight line.
For the relationship between measured integrated D/A output and voltage, see “Relationship between Output
Items and D/A Output Voltage.”
Setting the Rated Time for Integrated D/A Output
• You can set the hour, minute, and second within the following range.
00000:00:00 to 10000:00:00
• This setting is valid in the following integration modes.
• Manual integration mode
• Real-time normal integration mode when the integration timer is set to 00000:00:00
• In the following integration modes, the rated time for integrated D/A output is set to the same time that the
timer is set to.
• Standard integration mode
• Continuous integration mode
• Real-time normal integration mode when the integration timer is not set to 00000:00:00
• Real-time continuous integration mode
When the rated time for integrated D/A output is set to 00000:00:00, the D/A output for the integrated value is
fixed at 0 V.
