The output for an analog torque signal is +5 V when the torque reaches the value of the input range × the
torque scaling factor × the input signal slope (this is the rated value).* For example, when the input range is 10 V,
if the scaling factor is set to 1 N•m of torque per 1 V of input voltage, the output is +5 V when the torque is 10
N•m.
The output for a pulse torque signal is –5 V when the torque reaches the value specified for Pulse Range
Upper × –1, and the output is +5 V when the torque reaches the value specified for Pulse Range Upper.*
The output for an analog rotating speed signal is +5 V when the rotating speed reaches the value of the input
range × the revolution scaling factor × the input signal slope (this is the rated value).* For example, when the
input range is 10 V, if the scaling factor is set to 100 rpm per 1 V of input voltage, the output is + 5 V when the
rotating speed is 1000 rpm.
The output for a pulse rotating speed signal is –5 V when the rotating speed reaches the value specified for
Pulse Range Upper × –1, and the output is +5 V when the rotating speed reaches the value specified for
Pulse Range Upper.*
The output for SyncSp is +5 V when SyncSp is at the rated value for Speed.*
The output for Pm is +5 V when Pm reaches the motor output value obtained from the rated values for the
torque and rotating speed.
1
When the auxiliary signal is analog, the output for Aux is +5 V when Aux reaches the value of the analog
signal’s input range × the scaling factor for Aux × the auxiliary signal slope (this is the rated value).*
When the auxiliary signal is pulse, the output for Aux is –5 V when the auxiliary signal reaches the value
specified for Pulse Range Upper × –1, and the output is +5 V when the auxiliary signal reaches the value
specified for Pulse Range Upper.*
* Applies to models with the motor evaluation 1 or 2 option.
