York NM120-240 - Unit Dimensions NC;ND;NL;NM180

505428-YTG-V-0417
100 Johnson Controls Unitary Products
TOP VIEW
FRONT AND SIDE VIEW
Unit Dimensions NC/ND/NL/NM180
TOP VIEW - BLOWER OUTLET
Ø 1.718 KNOCKOUT FOR
ELECTRIC HEAT
23.85
18.84
3.79
26.34 21.82
10.00
10.50
FRONT VIEW - RETURN AIR
INDOOR
RIGHT SIDE VIEW - DRAIN PIPING/CONTROLS
SYSTEM 2
SYSTEM 1
6.44
1.88
17.85
15.50
13.13
10.73
7.12
75.00
42.00
27.53
2.00
2.00
70.50
74.50
7.06
3.66
4.56
1-1/4” CONDUIT
KNOCKOUT Ø 1.718
POWER ACCESS
33.00
FIELD PIPING
CONNECTIONS
DRAIN 3/4” ABS
PIPE CONNECTION
3/4” CONDUIT
KNOCKOUT Ø 1.093
CONTROLS ACCESS
