York NM120-240 - Unit Dimensions PC;PD180, PC;PD240, YC;YD180, YC;YD240

505428-YTG-V-0417
Johnson Controls Unitary Products 93
Unit Dimensions PC/PD180, PC/PD240, YC/YD180, YC/YD240
LEFT
RIGHT
FRONT
REAR
FRONT
FRONT
(PIPING DETAIL)
RIGHT
SYSTEM 2
SYSTEM 1
7.0007.000
23.000
37.000
64.000
2X (Ø 0.875)
KNOCKOUT
2X (Ø 1.375)
KNOCKOUT
7.0007.000
23.000
37.000
59.000
30.994
11.375
9.125
4.750
4.132
3.913
3.181
1.913
A
SYSTEM 2
SYSTEM 1
16.133
13.133
17.367
18.867
20.617
22.617
59.10
64.10
BASE RAIL
DETAIL
2.923
3.563
2.375
3.75
3.43
TOP
BOTTOM
1.33
2.097
