505428-YTG-V-0417
40 Johnson Controls Unitary Products
PC120/NC120/NL120
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
3000
77 140.5 7.5 70.2 58.2 46.2 - - - 134.2 8.6 65.0 52.8 40.6 - - -
72 133.6 7.5 87.5 75.5 63.5 51.5 - - 127.3 8.5 84.4 72.2 59.9 47.7 - -
67 126.6 7.4 104.8 92.8 80.8 68.9 56.9 - 120.3 8.5 103.8 91.5 79.3 67.1 54.8 -
62 120.2 7.4 120.2 120.2 107.7 95.7 83.8 71.8 113.2 8.4 113.2 113.2 101.2 88.9 76.7 64.5
57 121.8 7.3 121.8 123.0 114.5 102.5 90.5 78.6 117.1 8.4 117.1 117.1 106.6 94.4 82.2 69.9
3500
77 147.3 7.7 74.8 62.4 49.1 - - - 140.4 8.7 71.4 57.6 43.7 - - -
72 140.0 7.6 93.9 80.6 67.3 54.1 - - 133.2 8.7 92.3 78.4 64.6 50.7 - -
67 132.8 7.6 112.9 98.8 85.5 72.3 59.0 - 125.9 8.6 113.2 99.3 85.5 71.6 57.8 -
62 126.0 7.6 126.0 126.0 114.2 101.0 87.6 74.4 118.5 8.5 118.5 118.5 109.0 95.2 81.3 67.5
57 127.7 7.5 127.7 128.3 121.4 108.7 94.9 81.6 122.5 8.5 122.5 122.5 114.9 101.1 87.2 73.4
4000
77 154.1 7.8 79.4 66.6 52.0 - - - 146.6 8.9 77.8 62.3 46.9 - - -
72 146.5 7.8 100.2 85.7 71.1 56.6 - - 139.0 8.8 100.2 84.7 69.2 53.8 - -
67 138.9 7.8 121.1 104.8 90.2 75.7 61.1 - 131.5 8.7 122.5 107.1 91.6 76.2 60.7 -
62 131.8 7.8 131.8 131.8 120.6 106.3 91.5 76.9 123.7 8.7 123.7 123.7 116.9 101.4 86.0 70.5
57 133.6 7.6 133.6 133.6 128.3 114.8 99.2 84.6 127.9 8.6 127.9 127.9 123.2 107.7 92.3 76.8
4500
72 148.2 7.7 110.0 94.1 78.1 62.2 - - 140.9 8.7 108.1 91.5 74.8 58.1 - -
67 140.5 7.7 131.6 115.2 99.3 83.4 67.5 - 133.2 8.6 128.7 115.6 99.0 82.3 65.6 -
62 133.4 7.7 133.4 133.4 127.8 112.0 95.9 80.0 125.3 8.6 125.3 125.3 121.9 105.3 88.6 71.9
57 135.2 7.5 135.2 135.2 132.5 117.2 100.7 84.8 129.6 8.6 129.6 129.6 127.2 110.6 93.9 77.2
5000
72 150.0 7.6 119.7 102.4 85.1 67.9 - - 142.7 8.6 116.1 98.2 80.3 62.5 - -
67 142.2 7.5 142.2 125.6 108.3 91.1 73.8 - 134.9 8.5 134.9 124.2 106.3 88.4 70.5 -
62 134.9 7.5 134.9 134.9 134.9 117.6 100.4 83.1 127.0 8.5 127.0 127.0 127.0 109.1 91.2 73.3
57 136.7 7.4 136.7 136.7 136.7 119.5 102.2 84.9 131.3 8.5 131.3 131.3 131.3 113.4 95.5 77.6
95°F 105°F
3000
77 128.0 9.7 59.9 47.4 34.9 - - - 120.6 10.9 59.2 46.6 34.0 - - -
72 121.0 9.6 81.3 68.8 56.3 43.8 - - 113.1 10.8 79.6 67.0 54.4 41.8 - -
67 114.1 9.5 102.8 90.3 77.8 65.3 52.8 - 105.6 10.7 100.0 87.4 74.7 62.1 49.5 -
62 106.3 9.3 106.3 106.3 94.7 82.2 69.7 57.2 101.1 10.6 101.1 101.1 90.6 78.0 65.4 52.8
57 112.4 9.5 112.4 111.3 98.8 86.3 73.8 61.3 104.8 10.7 104.8 104.2 92.7 80.1 67.5 54.9
3500
77 133.6 9.8 68.0 52.7 38.3 - - - 126.1 11.0 69.7 51.8 37.3 - - -
72 126.3 9.7 90.7 76.3 61.9 47.4 - - 118.3 10.9 88.6 74.1 59.6 45.1 - -
67 119.0 9.6 113.4 99.8 85.4 71.0 56.5 - 110.4 10.8 107.6 96.5 82.0 67.5 53.0 -
62 111.0 9.4 111.0 111.0 103.9 89.4 75.1 60.6 105.7 10.7 105.7 105.7 99.3 84.8 70.3 55.8
57 117.3 9.6 117.3 116.7 108.4 93.4 79.6 65.1 109.5 10.8 109.5 109.3 101.6 86.9 72.6 58.1
4000
77 139.1 9.9 76.2 58.1 41.7 - - - 131.6 11.1 80.1 56.9 40.5 - - -
72 131.6 9.8 100.1 83.7 67.4 51.0 - - 123.4 11.0 97.7 81.3 64.9 48.5 - -
67 124.0 9.7 124.0 109.4 93.0 76.6 60.3 - 115.2 10.9 115.2 105.6 89.2 72.8 56.4 -
62 115.6 9.5 115.6 115.6 113.2 96.5 80.5 64.1 110.3 10.8 110.3 110.3 108.1 91.6 75.3 58.9
57 122.2 9.7 122.2 122.2 118.1 100.6 85.4 69.0 114.3 10.9 114.3 114.3 110.6 93.6 77.8 61.4
4500
72 133.5 9.7 106.3 88.9 71.5 54.0 - - 124.9 10.9 104.6 86.9 69.3 51.7 - -
67 125.8 9.6 125.8 116.1 98.6 81.2 63.8 - 116.6 10.8 116.6 110.6 95.3 77.7 60.1 -
62 117.3 9.5 117.3 117.3 116.1 98.5 81.2 63.8 111.6 10.7 111.6 111.6 110.5 92.8 75.3 57.6
57 124.0 9.6 124.0 124.0 122.0 104.0 87.1 69.7 115.7 10.8 115.7 115.7 113.8 95.9 78.6 61.0
5000
72 135.4 9.6 112.5 94.0 75.5 57.0 - - 126.3 10.9 111.5 92.6 73.8 55.0 - -
67 127.6 9.5 127.6 122.8 104.3 85.8 67.3 - 118.0 10.8 118.0 115.5 101.5 82.6 63.8 -
62 119.0 9.4 119.0 119.0 119.0 100.5 82.0 63.5 112.9 10.7 112.9 112.9 112.9 94.1 75.2 56.4
57 125.8 9.5 125.8 125.8 125.8 107.3 88.8 70.3 117.0 10.7 117.0 117.0 117.0 98.2 79.4 60.5
