YC240/NC240NL240
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
6000
77 286.3 15.3 136.1 113.4 90.6 - - - 280.0 16.9 131.5 108.2 84.9 - - -
72 267.4 14.8 169.4 146.7 123.9 101.2 - - 260.2 16.5 166.3 143.0 119.7 96.4 - -
67 248.5 14.4 202.7 180.0 157.2 134.5 111.7 - 240.5 16.1 201.0 177.7 154.4 131.1 107.8 -
62 228.9 14.1 228.9 216.8 194.0 171.3 148.5 125.8 223.4 15.7 223.4 213.8 190.5 167.2 143.9 120.6
57 227.5 14.0 227.5 227.5 205.1 182.4 159.6 136.9 220.8 15.7 220.8 220.8 201.8 178.5 155.2 131.9
7000
77 296.6 15.4 148.2 122.8 97.4 - - - 287.9 17.0 143.1 117.2 91.3 - - -
72 277.0 14.9 184.0 158.6 133.2 107.8 - - 267.6 16.6 180.5 154.5 128.6 102.7 - -
67 257.5 14.5 219.8 194.4 169.0 143.6 118.3 - 247.4 16.1 217.8 191.9 165.9 140.0 114.1 -
62 237.1 14.2 237.1 231.1 208.6 184.8 157.8 132.4 229.7 15.8 229.7 224.9 204.7 178.7 152.8 126.9
57 235.7 14.1 235.7 235.7 220.5 197.5 169.7 144.3 227.0 15.8 227.0 227.0 216.9 190.9 165.0 139.0
8000
77 306.9 15.5 160.3 132.3 104.2 - - - 295.8 17.1 154.7 126.2 97.6 - - -
72 286.6 15.0 198.6 170.6 142.5 114.5 - - 275.0 16.7 194.7 166.1 137.5 108.9 - -
67 266.4 14.6 236.9 208.9 180.8 152.8 124.8 - 254.2 16.2 234.6 206.0 177.4 148.8 120.3 -
62 245.4 14.3 245.4 245.4 223.1 198.3 167.1 139.0 236.1 15.9 236.1 236.1 218.8 190.3 161.7 133.1
57 243.8 14.2 243.8 243.8 235.9 212.7 179.8 151.8 233.3 15.9 233.3 233.3 231.9 203.3 174.7 146.2
9000
72 296.2 15.1 209.5 179.3 149.0 118.8 - - 282.3 16.7 205.3 174.3 143.2 112.2 - -
67 275.2 14.7 251.9 219.4 189.1 158.9 128.6 - 261.0 16.3 246.8 215.8 184.8 153.8 122.8 -
62 253.5 14.4 253.5 253.5 233.4 204.7 172.9 142.6 242.4 15.9 242.4 242.4 228.0 197.0 165.9 134.9
57 251.9 14.3 251.9 251.9 248.0 220.1 187.5 157.2 239.5 15.9 239.5 239.5 238.8 207.8 176.8 145.8
10000
72 305.7 15.2 220.5 188.0 155.6 123.1 - - 289.7 16.8 215.9 182.4 149.0 115.5 - -
67 284.0 14.8 266.9 229.9 197.4 165.0 132.5 - 267.7 16.3 259.1 225.7 192.2 158.8 125.3 -
62 261.7 14.5 261.7 261.7 243.6 211.1 178.7 146.2 248.7 16.0 248.7 248.7 237.1 203.7 170.2 136.8
57 260.0 14.4 260.0 260.0 260.0 227.6 195.1 162.7 245.7 16.0 245.7 245.7 245.7 212.3 178.8 145.4
95°F 105°F
6000
77 273.6 18.5 126.9 103.1 79.2 - - - 259.0 21.0 123.8 99.6 75.3 - - -
72 253.1 18.1 163.1 139.3 115.4 91.6 - - 239.6 20.4 159.8 135.6 111.3 87.1 - -
67 232.5 17.7 199.3 175.5 151.6 127.8 103.9 - 220.3 19.9 195.8 171.6 147.4 123.1 98.9 -
62 217.9 17.3 217.9 210.8 186.9 163.1 139.2 115.4 205.1 19.5 205.1 201.5 182.5 158.3 134.0 109.8
57 214.0 17.4 214.0 214.0 198.6 174.7 150.9 127.0 204.2 19.6 204.2 204.2 186.7 162.4 138.2 114.0
7000
77 279.2 18.6 138.0 111.6 85.1 - - - 264.6 21.0 137.3 108.0 81.0 - - -
72 258.2 18.2 176.9 150.4 123.9 97.5 - - 244.8 20.5 173.8 146.8 119.7 92.7 - -
67 237.3 17.8 215.8 189.3 162.8 136.3 109.9 - 225.0 20.0 210.4 185.5 158.5 131.4 104.4 -
62 222.3 17.4 222.3 218.8 200.7 172.6 147.8 121.3 209.5 19.5 209.5 207.7 196.3 168.4 142.2 115.1
57 218.4 17.5 218.4 218.4 213.2 184.3 160.3 133.8 208.6 19.6 208.6 208.6 200.7 172.5 146.6 119.6
8000
77 284.7 18.7 149.2 120.1 90.9 - - - 270.2 21.1 150.8 116.5 86.7 - - -
72 263.4 18.3 190.7 161.6 132.5 103.4 - - 250.0 20.6 187.8 158.0 128.1 98.2 - -
67 242.0 17.9 232.2 203.1 174.0 144.9 115.8 - 229.8 20.0 224.9 199.4 169.6 139.7 109.8 -
62 226.8 17.5 226.8 226.8 214.5 182.2 156.3 127.2 213.9 19.6 213.9 213.9 210.0 178.5 150.3 120.4
57 222.7 17.5 222.7 222.7 227.9 193.9 169.6 140.5 213.0 19.7 213.0 213.0 214.8 182.5 155.0 125.2
9000
72 268.5 18.3 201.0 169.2 137.4 105.7 - - 255.2 20.7 198.4 166.0 133.5 101.1 - -
67 246.7 17.9 241.8 212.3 180.5 148.7 117.0 - 234.6 20.1 232.1 209.2 176.8 144.3 111.9 -
62 231.2 17.5 231.2 231.2 222.6 189.2 159.0 127.2 218.4 19.7 218.4 218.4 215.2 181.9 150.3 117.8
57 227.1 17.5 227.1 227.1 229.6 195.4 166.1 134.3 217.5 19.8 217.5 217.5 218.3 184.7 153.4 121.0
10000
72 273.6 18.3 211.3 176.8 142.4 108.0 - - 260.4 20.7 209.0 174.0 139.0 104.0 - -
67 251.4 17.9 251.4 221.5 187.0 152.6 118.2 - 239.3 20.2 239.3 219.0 184.0 148.9 113.9 -
62 235.6 17.5 235.6 235.6 230.6 196.2 161.7 127.3 222.8 19.8 222.8 222.8 220.3 185.3 150.3 115.2
57 231.4 17.5 231.4 231.4 231.4 196.9 162.5 128.1 221.9 19.9 221.9 221.9 221.9 186.9 151.8 116.8
