505428-YTG-V-0417
38 Johnson Controls Unitary Products
Heat Pump and Air Handling Cooling Capacities
PC090/NC090/NL090 Cooling Capacities
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
2250
77 112.8 5.9 54.5 44.9 35.3 - - - 107.0 6.5 51.9 42.4 32.9 - - -
72 104.8 5.8 68.7 59.1 49.5 40.0 - - 99.3 6.4 66.3 56.8 47.3 37.9 - -
67 96.7 5.7 82.9 73.4 63.8 54.2 44.6 - 91.7 6.3 80.8 71.3 61.8 52.3 42.8 -
62 89.0 5.5 89.0 89.0 80.5 70.9 61.3 51.7 84.4 6.2 84.4 84.4 76.5 67.0 57.5 48.0
57 88.9 5.6 88.9 88.9 80.5 70.9 61.4 51.8 84.6 6.2 84.6 84.6 75.7 66.2 56.8 47.3
2625
77 117.0 5.9 58.7 48.7 37.9 - - - 110.7 6.6 57.0 46.2 35.5 - - -
72 108.6 5.8 74.8 64.0 53.2 42.5 - - 102.7 6.5 72.5 61.8 51.1 40.4 - -
67 100.3 5.7 90.9 79.3 68.5 57.8 47.0 - 94.8 6.3 88.1 77.4 66.7 56.0 45.3 -
62 92.3 5.6 92.3 92.3 86.5 76.2 64.9 54.1 87.3 6.2 87.3 87.3 82.6 71.9 61.1 50.4
57 92.2 5.6 92.2 92.2 86.6 76.3 65.0 54.2 87.5 6.2 87.5 87.5 81.7 71.0 60.3 49.6
3000
77 121.1 5.9 63.0 52.6 40.6 - - - 114.3 6.6 62.0 50.1 38.1 - - -
72 112.5 5.8 80.9 68.9 56.9 45.0 - - 106.1 6.5 78.7 66.8 54.9 42.9 - -
67 103.8 5.7 98.9 85.3 73.3 61.3 49.3 - 97.9 6.4 95.4 83.5 71.6 59.6 47.7 -
62 95.6 5.6 95.6 95.6 92.5 81.5 68.6 56.6 90.2 6.3 90.2 90.2 88.6 76.7 64.8 52.8
57 95.4 5.6 95.4 95.4 92.6 81.7 68.6 56.6 90.4 6.2 90.4 90.4 87.7 75.8 63.9 51.9
3375
72 114.6 5.8 88.6 75.6 62.6 49.6 - - 108.6 6.5 85.9 73.0 60.0 47.1 - -
67 105.7 5.7 103.3 93.6 80.6 67.6 54.6 - 100.3 6.4 99.0 91.3 78.3 65.4 52.4 -
62 97.4 5.6 97.4 97.4 95.8 83.3 69.8 56.8 92.3 6.3 92.3 92.3 91.6 78.6 65.7 52.7
57 97.2 5.6 97.2 97.2 95.8 83.3 69.7 56.7 92.5 6.3 92.5 92.5 91.2 78.3 65.3 52.3
3750
72 116.6 5.8 96.3 82.3 68.3 54.2 - - 111.2 6.5 93.1 79.2 65.2 51.2 - -
67 107.7 5.7 107.7 101.9 87.9 73.8 59.8 - 102.6 6.4 102.6 99.0 85.1 71.1 57.1 -
62 99.1 5.6 99.1 99.1 99.1 85.1 71.0 57.0 94.5 6.3 94.5 94.5 94.5 80.5 66.5 52.6
57 99.0 5.6 99.0 99.0 99.0 84.9 70.9 56.8 94.7 6.3 94.7 94.7 94.7 80.7 66.7 52.8
95°F 105°F
2250
77 101.2 7.2 49.3 39.9 30.6 - - - 100.5 8.0 59.5 50.1 40.7 - - -
72 93.9 7.1 63.9 54.6 45.2 35.8 - - 90.2 7.9 67.7 58.3 48.9 39.4 - -
67 86.6 7.0 78.6 69.2 59.8 50.4 41.0 - 79.9 7.8 75.8 66.4 57.0 47.6 38.2 -
62 79.8 6.9 79.8 79.8 72.5 63.1 53.7 44.4 74.8 7.7 74.8 74.8 67.3 57.9 48.5 39.0
57 80.3 6.8 80.3 80.3 70.9 61.5 52.1 42.8 74.9 7.7 74.9 74.9 65.7 56.2 46.8 37.4
2625
77 104.3 7.3 55.2 43.8 33.1 - - - 103.7 8.0 68.8 55.1 44.4 - - -
72 96.8 7.1 70.2 59.6 49.0 38.3 - - 93.0 8.0 74.6 63.9 53.3 42.6 - -
67 89.3 7.0 85.3 75.4 64.8 54.2 43.5 - 82.4 7.9 80.4 72.8 62.1 51.4 40.8 -
62 82.3 6.9 82.3 82.3 78.6 67.5 57.4 46.7 77.2 7.7 77.2 77.2 73.3 62.4 52.0 41.3
57 82.8 6.9 82.8 82.8 76.9 65.7 55.6 45.0 77.2 7.7 77.2 77.2 71.5 60.6 50.2 39.5
3000
77 107.5 7.3 61.0 47.6 35.7 - - - 106.8 8.1 78.1 60.0 48.1 - - -
72 99.7 7.2 76.5 64.6 52.8 40.9 - - 95.9 8.0 81.5 69.6 57.7 45.8 - -
67 92.0 7.0 92.0 81.7 69.8 57.9 46.1 - 84.9 7.9 84.9 79.1 67.2 55.3 43.4 -
62 84.7 6.9 84.7 84.7 84.7 71.9 61.0 49.1 79.6 7.8 79.6 79.6 79.3 66.9 55.5 43.6
57 85.3 6.9 85.3 85.3 82.9 69.9 59.1 47.2 79.6 7.7 79.6 79.6 77.4 64.9 53.6 41.6
3375
72 102.7 7.2 83.2 70.3 57.4 44.6 - - 98.8 8.0 87.6 76.1 63.2 50.2 - -
67 94.8 7.1 94.8 88.9 76.0 63.1 50.2 - 87.5 7.9 87.5 84.2 73.6 60.6 47.7 -
62 87.3 6.9 87.3 87.3 87.3 73.9 61.5 48.6 82.0 7.8 82.0 82.0 81.8 68.6 55.9 43.0
57 87.8 6.9 87.8 87.8 86.6 73.2 60.8 48.0 82.0 7.8 82.0 82.0 80.9 67.7 55.0 42.1
3750
72 105.7 7.2 89.9 76.0 62.1 48.2 - - 101.7 8.0 93.8 82.7 68.7 54.7 - -
67 97.5 7.1 97.5 96.1 82.2 68.3 54.4 - 90.1 7.9 90.1 89.4 79.9 65.9 52.0 -
62 89.8 7.0 89.8 89.8 89.8 75.9 62.0 48.1 84.4 7.8 84.4 84.4 84.4 70.4 56.4 42.4
57 90.4 6.9 90.4 90.4 90.4 76.5 62.6 48.7 84.4 7.8 84.4 84.4 84.4 70.5 56.5 42.5
To Next Page
