York NM120-240 - Configured Split Condenser Model Number Nomenclature; Configured Split Air Handler Model Number Nomenclature; Nomenclature

505428-YTG-V-0417
Johnson Controls Unitary Products 3
Nomenclature
Product Category
Y = Split System, Condenser, AC, R-410A
Product Identifier
C = Standard Efficiency, 2-Pipe, R-410A
D = Standard Efficiency, 4-Pipe, R-410A
Nominal Cooling Capacity - MBH
090 = 7.5 Ton
120 = 10 Ton
150 = 12.5 Ton
180 = 15 Ton
240 = 20 Ton
300 = 25 Ton
C00 = Cooling Only
Product Options
AA = None
AB = Phase Monitor
AC = Coil Guard
AE = Phase Monitor + Coil Guard
EA = E-Coat Condenser Coil
EB = E-Coat Condenser Coil + Phase Monitor
EC = E-Coat Condenser Coil + Coil Guard
EE = E-Coat Condenser Coil + Coil Guard
+ Phase Monitor
LA = Low Ambient
LB = Low Ambient + Phase Monitor
LC = Low Ambient + Coil Guard
LD = Low Ambient + Phase Monitor
+ Coil Guard
LE = Low Ambient + Technicoat Cond. Coil
LF = Low Ambient + Technicoat Cond. Coil
+ Phase Monitor
LG = Low Ambient + Technicoat Cond. Coil
+ Coil Guard
LH = Low Ambient + Technicoat Cond. Coil
+ Phase Monitor + Coil Guard
LJ = Low Ambient + ElectroFin Cond. Coil
LK = Low Ambient + ElectroFin Cond. Coil
+ Phase Monitor
LL = Low Ambient + ElectroFin Cond. Coil
+ Coil Guard
LM = Low Ambient + ElectroFin Cond. Coil
+ Phase Monitor + Coil Guard
TA = Technicoat Condenser Coil
TB = Technicoat Condenser Coil + Phase
Monitor
TC = Technicoat Condenser Coil + Coil Guard
TE = Technicoat Condenser Coil + Coil Guard
+ Phase Monitor
Installation Options
A = None
B = Option 1
C = Option 2
D = Options 1 & 2
E = Option 3
G = Options 1 & 3
H = Options 2 & 3
J = Options 1, 2 & 3
P = Options 3 & 5
Q = Options 1, 3 & 5
S = Option 5
T = Options 1 & 5
2 = 208/230-3-60
4 = 460-3-60
5 = 575-3-60
1
Configured Split Condenser Model Number Nomenclature
A = Standard Motor
Airflow
Product Generation
5 = Fifth Generation
Voltage
Heat Type & Nominal Heat Capacity
Y
C
300
C00 A
2
A
AA
5
A
Product Style
A = Style A
P = Split System, Condenser, HP, R-410A
1 = Disconnect
2 = Non Pwr’d Conv Outlet
3 = BACnet MS/TP on Smart Equipment™
5 = Pwr’d Conv Outlet
Options
1. 575 Volt PC Not Offered.
Product Category
N = Split System, Air Handler, AC & HP R-410A
Product Identifier
C = Standard Efficiency, 2-Pipe, R-410A
D = Standard Efficiency, 4-Pipe, R-410A
Nominal Cooling Capacity - MBH
090 = 7-1/2 Ton Avialable in 2-Pipe Only
120 = 10 Ton
180 = 15 Ton
240 = 20 Ton
300 = 25 Ton
3
C00 = Cooling Only
Product Options
AA = No Options Installed
EJ = E-Coat Evaporator Coil
TJ = Technicoat Evaporator Coil
Installation Options
A = None
2 = 208/230-3-60
2
4 = 460-3-60
2
5 = 575-3-60
6 = 208/230/460-3-60
Configured Split Air Handler Model Number Nomenclature
B = 1.5 HP Motor
C = 2.0 HP Motor
D = 3.0 HP Motor
E = 5.0 HP Motor
F = 7.5 HP Motor
N = None (Motor Drive Kit Reg)
1
Airflow
Product Generation
1 = First Generation
2 = Second Generation
3 = Third Generation
Voltage
Heat Type & Nominal Heat Capacity
N
C
240
C00 B
6
A
AA
3
A
Product Style
A = Style A
1. Motors are not shipped with 25 ton AH units.
2. Models NC/ND240 Airflow Option "F" Only.
3. ND 300 Not Offered
