York NM120-240 - Unit Dimensions NC090;120, NL090;120, ND120 and NM120

505428-YTG-V-0417
98 Johnson Controls Unitary Products
TOP VIEW
FRONT AND SIDE VIEW
Unit Dimensions NC090/120, NL090/120, ND120 and NM120
20.31
13.44
8.22
17.59 15.63
8.84
9.25
Ø 1.72 KNOCKOUT
ELECTRIC HEAT
Ø 1.718 KNOCKOUT FOR
ELECTRIC HEAT
20.313
8.837
9.246
15.920
14.590
5.135
18.628
TOP VIEW - BLOWER OUTLET
7.5 TON INDOOR
TOP VIEW - BLOWER OUTLET
10 TON INDOOR
1-1/4” CONDUIT
KNOCKOUT Ø 1.718
POWER ACCESS
65.000
35.000
20.531
52.000
56.000
2.000
2.000
7.06
3.66
4.56
3/4” CONDUIT
KNOCKOUT Ø 1.093
CONTROLS ACCESS
FIELD PIPING
CONNECTIONS
SYSTEM 2
SYSTEM 1
6.38
17.85
15.50
13.13
10.73
1.88
7.12
FRONT VIEW - RETURN AIR
7.5 - 10 TON INDOOR
RIGHT SIDE VIEW - DRAIN PIPING/CONTROLS
30.00
DRAIN 3/4” ABS
PIPE CONNECTION
