Zamboni 445 - Page 76

8 - 2
Water System
Wash Water Pipe (A)
Ice Making Water
Pipe (C)
Wash Water Transfer
Valve (D) Optional
Wash Water Distribution Pipe
Wash Water Outlet (Both
Ends Of Conditioner)
Wash Water Pickup (Suction)
Blade Adjustment Screw &
Greasable Clevis
Figure 8.2 Conditioner Underside
Pipe (B)
