Maintaining the Cutting Blade
9 - 9
Figure 9.9 Edger Attachment
Edger Attachment
Mount the edger on the driver's side of the conditioner and bolt tightly at the three locations
shown below. The depth of cut on the edger blade may be adjusted by turning the two blade
adjustment set screws.
Use the edger as a separate operation in the following manner:
• Start driving slowly next to boards. Fully lower conditioner, but raise the
conditioner blade off of the ice, slightly, by turning the blade adjustment
hand wheel counter-clockwise.
• Start conveyors.
• Take one or two laps along the side of your boards, keeping the edger against
the railing or dasher.
• Remove the edger assembly.
• Resurface the ice rink completely in the normal manner.
CAUTION:
Drive slowly when using the edger. While using the
edger, the front of the resurfacer will tend to pull into
the wall.
Note: Keep edger blade sharp.
Edger Mounting Bolts
Blade Adjusting Screws
Blade
Forward
Forward
