Page 58
The following table shows all the values of parameters.
PARAMETER PROGRAMMED LEVEL
UNIT0123456789
PUMP ACCELER DELAY (*) Sec. 0.2 0.4 0.6 0.8 1 1.5 2 2.5 3 3.5
PUMP DECELER DELAY (**) Sec. 0.2 0.4 0.6 0.8 1 1.5 2 2.5 3 3.5
SPEED LIMIT % 0 - 100
CREEP SPEED % 0 - 100
COMPENSATION % 0 - 100
1ST SPEED FINE % 0 - 100
1ST SPEED COMP % 0 - 100
2ND SPEED FINE % 0 - 100
2ND SPEED COMP % 0 - 100
3RD SPEED FINE % 0 - 100
3RD SPEED COMP % 0 - 100
4TH SPEED FINE % 0 - 100
4TH SPEED COMP % 0 - 100
5TH SPEED FINE % 0 - 100
5TH SPEED COMP % 0 - 100
HYDRO SPEED FINE % 0 - 100
HYDRO SPEED COMP % 0 - 100
HYDRO TIME Sec. 0 - 25.5
PUMP IMAX %IMAX505561667277838894100
(*) The acceleration time shown is the theoretical time to change from 0V to full voltage
applied to the motor. This is an ideal ramp, the real ramp can change as a function of
the load.
(**) The deceleration feature is based upon deceleration ramps. The value shown in the
table is the time to decrease the voltage applied to the motor from 100% down to
0%.
