Zapi EPS-BLI HYG - ADJUSTMENTS List

AFMNA0AA – EPS-BLI HYG – User Manual Page – 27/75
9.2.2 ADJUSTMENTS list
To enter and navigate the ADJUSTMENT list by the Zapi hand set go down the following
procedure.
Opening Zapi lines.
EPSHTM 6U NAx.xx
24 V 50 A 00000
Press ROLL UP + SET UP simultaneously to enter
CONFIG MENU.
% ' %
' ' '
The display will show: SET MODEL.
CONFIG MENU
SET MODEL
Press ROLL UP or ROLL DOWN until
ADJUSTMENTS appears.
% ' '
% ' '
The display will show: ADJUSTMENTS.
CONFIG MENU
ADJUSTMENTS
Press ENTER to go into the ADJUSTMENTS
menu.
' % '
' ' '
The display will show the first parameter and its
actual setting.
ADJUSTMENT #01
LEVEL= 0
Press ROLL UP or ROLL DOWN to scroll the
parameters.
% ' '
% ' '
The display will show the desired parameter and its
actual setting.
AUX OUT 2 D.C.
100%
Press SET UP or SET DOWN to modify the setting.
' ' %
' ' %
The display will show the new setting.
AUX OUT 2 D.C.
95%
Press OUT to exit the menu.
' ' '
' % '
The display will ask “ARE YOU SURE?”.
ARE YOU SURE?
YES=ENTER NO=OUT
Press ENTER for yes, OUT for no.
' % '
' ' '
' ' '
' % '
The display will show: ADJUSTMENTS.
CONFIG MENU
ADJUSTMENTS
Press OUT again. Display will show the opening
Zapi lines.
' ' '
' % '
