Zapi EPS-BLI HYG - TESTER List

Page – 44/75 AFMNA0AA – EPS-BLI HYG – User Manual
9.2.7 TESTER list
The TESTER list gives real time readouts of the state of the controller. It is possible to
know the state of digital I/Os (active or inactive), the voltage value of analog inputs
and the state of the main variables used in the motor.
Opening Zapi lines.
EPSHTM 6U NAx.xx
24 V 50 A 00000
Press ENTER to go into the main menu.
' % '
' ' '
The display will show: PARAMETER CHANGE.
MAIN MENU
PARAMETER CHANGE
Press ROLL UP or ROLL DOWN until TESTER
appears.
% ' '
% ' '
The display will show: TESTER.
MAIN MENU
TESTER
Press ENTER to go into the TESTER menu.
' % '
' ' '
The display will show the first readout.
SET POINT ONE
0
Press ROLL UP or ROLL DOWN to scroll the
readouts.
% ' '
% ' '
The display will show the desired readout and its
actual value.
MOTOR CURRENT
0A
Press OUT to exit the menu.
' ' '
' % '
The display will show: TESTER.
CONFIG MENU
TESTER
Press OUT again. Display will show the opening
Zapi lines.
' ' '
' % '
1) SETPOINT ANGLE 1
Unit: degrees.
Angle of the first set-point sensor.
2) SETPOINT ANGLE 2
Unit: degrees.
Angle of the second set-point sensor.
3) SP DUTY CYCLE 1
Unit: percentage.
Duty cycle of the PWM from the first set-point sensor.
4) SP DUTY CYCLE 2
Unit: percentage.
