Zapi EPS-BLI HYG - PARAMETER CHANGE List

Page – 32/75 AFMNA0AA – EPS-BLI HYG – User Manual
9.2.4 PARAMETER CHANGE list
To enter and navigate the ADJUSTMENT list by the Zapi hand set go down the
following procedure.
Opening Zapi lines.
EPSHTM 6U NAx.xx
24 V 50 A 00000
Press ENTER to go into the main menu.
' % '
' ' '
The display will show: PARAMETER CHANGE.
MAIN MENU
PARAMETER CHANGE
Press ENTER to go into the PARAMETER
CHANGE list.
' % '
' ' '
The display will show the first parameter and its
actual setting.
POTI REVOLUTIONS
3.8
Press ROLL UP or ROLL DOWN to scroll the
parameters.
% ' '
% ' '
The display will show the desired parameter and its
actual setting.
FINAL NUMB SPEED
50%
Press SET UP or SET DOWN to modify the setting.
' ' %
' ' %
The display will show the new setting.
FINAL NUMB SPEED
60%
Press OUT to exit the menu.
' ' '
' % '
The display will ask “ARE YOU SURE?”.
ARE YOU SURE?
YES=ENTER NO=OUT
Press ENTER for yes, OUT for no.
' % '
' ' '
' ' '
' % '
The display will show: PARAMETER CHANGE.
CONFIG MENU
PARAMETER CHANGE
Press OUT again. Display will show the opening
Zapi lines.
' ' '
' % '
1) SENS FILTER MSEC
Milliseconds, 1 through 1000. Default value is 20 ms.
This parameter defines the time constant of the digital filter applied to the steering
set point.
2) PWM FREQ 4 8 16K
kHz, can be 4 kHz, 8 kHz and 16 kHz. Default value is 16 kHz.
This parameter defines the switching frequency of the inverter.
