Page – 8/75 AFMNA0AA – EPS-BLI HYG – User Manual
2.2 Technical specifications
Modulation strategy: .................................................................... center-aligned PWM
Operating frequency: ........................................................................................... 8 kHz
External temperature range: .................................................................. -30 °C ÷ 40 °C
Maximum inverter temperature:........................................................................... 90 °C
International protection marking: ........................................................................... IP65
2.3 Electrical specifications
Nominal supply voltage: ....................................................................................... 24 V
Nominal maximum current: ............................................................................. 50 Arms
Maximum time at maximum current: .............................................. 2’ (alarm after 5 s)
Minimum battery voltage: .................................................................................. 12.5 V
Maximum battery voltage: .................................................................................... 35 V
Minimum input (key) supply voltage after start-up: ............................................ 12.5 V
Auxiliary circuits (key input) fuse rating: ...................................................... max 6.3 A
Power fuse rating (proposal): ..................................................................... max 40 A*
CAN bus communication speed: ......................................................... up to 500 kbps
* Rated tripping current of the fuse should be selected according to the current-carrying
capacity of cables and connections.
2.4 Motor specifications
Type: ...................................................................................................... brushless AC
Manufacturer: .......................................................................................... InMotion US
Model: ....................................................................................................... Boise Motor
Power: ................................................................................................... 600 W S2 1 h
Speed: .......................................................................................................... 3000 rpm
Max motor torque @ Imax = 50 Arms: ..................................... 3.1 Nm @ Vbatt = 24V
Gear box: ........................................................................ Sumitomo CNVMS-5087-43
Total gear box ratio: .............................................................................................. 1:43
Thermal sensor: ............................................................................................. PT-1000
