Deva 5.8 and Deva 16 Owner’s Manual
Chapter 1
7
10. Battery Compartment
The black knob rotates to lock the battery compartment door. Use NP-1 type batteries with the Deva. You can
safely use Li-ion and NiMH NP-1 batteries in the Deva as long as their maximum voltage does not exceed
18 VDC.
11. Power Input Connector
Standard 4-pin XLR connector for 9.5V-18VDC 1 Amp input
Note: At this time the REF 1 connector does not function.
Right Side Panel Description
Figure 3 Deva Right panel
1. Mic / Line Inputs 1 through 8
Each balanced input is internally padded to handle either mic or line level signals. The signal level is selected using
the Input Control screen. (Line Input Impedance is 4 K
Ω).
5
1
2
3
4
Deva 5.8
5
1
2
3
6
Deva 16
