25/67
Identification: MD-AL-GI-00
Rev. 1.2 07.06.21 - Application: GID
Connext User Manual
Rev. 2.2 10/01/2023
Figure 16 - RS485 connections to single-phase hybrid inverter
Figure 17 - Connections on single-phase hybrid inverter
RS485 Pin
24-pin terminal block
RS485 + (Red)
9
RS485 – (Black)
10
Table 9 - RS485 connections to 3000SP inverter
CAN/485m/485s
